125KHZ RFID Card Reader Small Waterproof Good Quality Biometric Access Control Card Reader ZK KR100

Share on:


Price:RUB 396.91 - RUB 793.81
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

The KR Series is the main accessories line of external wiegand readers for all our access control devices. With an elegant and robust design, they are easy to connect and install, and offer the possibility to control one door from both sides. The LED lights indicate allowed or denied access. They have a proximity reading range of up to 10cm in the E series case and up to 5cm in the M series case. The fact that this series is waterproof, and the operating temperatures can range from -20º to +65º, it is the ideal solution for outdoor installation. Also they can be connected with our wiegend controllers.
Features:
Easy to install
125KHz Proximity/13.56MHz Mifare Card Reader
Read Range: Up to 10CM(125KHz)/5CM(13.56MHz)
26/34bit Wiegand (default)
Easy to install on Metal Door Frame or Mullion
External LED Control
External Buzzer Control
Indoor / Outdoor Operation
Solid Epoxy Injection
Waterproof IP65
Reverse Polarity Protection
Elegant and robust design
Specification
Model
KR100E/M
KR101E/M
KR102E/M
KR200E/M
KR201E/M
KR202E/M
KR300
Read Rang
E Serious: Up To 10cm, M Serious: Up To 5cm
Up to 10cm
Read Time
300ms
Power
DC 6-14V/ Max 70mA
Input Port
2ea (External LED Control, External Buzzer Control)
Output Format
26 bit Wiegand (E); 34 bit Wiegand (M)
Output Pin
N
N
8 bits
N
N
8 bits
N
LED indicator
2 Color Led Indicators( Red And Green)
Beeper
Support
Operating Temperature
-20℃-+65℃
Operating Humidity
10%-90%(Relative Humidity non-considered)
Color
Black
Black
Black
Black
Black
Black
Black
Material
ABS+PC with texture
Dimension:mm
116*75*17.3
77.5*42.8*16.5
86*86*16.3
86*86*16.8
84.5*44*16.8
87*86*22.4
77.5*42.8*16.5
Weight
120g
50g
120g
110g
55g
126g
50g
index Of Protection
IP65
IP65
IP64
IP65
IP65
IP64
IP65
