SHLX-PV PV combiner box bus synthetic DC input of 8 PV components to 1 output. Each channel is with a fuse. Output side is equipped with lightning protection and circuit breaker. It greatly simplify input wiring of DC power distribution cabinet and inverter. Realize lightning protecion, short circuit protection and grounding protection. PV combiner box divided into two types: intrlligent box and non-intelligent box . Intelligent PV combiner box is equipped with monitoring unit, then detect input current of each string, detect inside temperature, detect lightning protection status, detect circuit breaker status and summarize output voltage and so on.
Design and configuration strictly accordance with the "Technical specification for photovoltaic junction equipment" CGC/GF 037:2014.
Provide users with a safe, brief, beautiful and applicable photovoltaic system products.
The product adopts outdoor wall mounted type, which adapt to the harsh environment. In addition to the core components, the other can be customized by users requirements.
System maximum dc voltage
Maximum input current for each string
Maximum input strings
Maximum output switch current
Number of inverter MPPT
Number of output strings
Category of test
‖ grade protection
Nominal discharge current
Maximum discharge current
Voltage protection level
Maximum continuous operating voltage Uc
DC isolation switch(standard)/DC circuit breaker(optional)
SMC4 Connectors/dc fuse/dc surge protector
Monitoring module/Preventing diode
Wall mounting type
Elevation of temperature
Permissible relative humidity
0-95%, no condensation
1. With DC FUSE
2. With DC Surge Protection Device
3. With DC circuit breaker or DC load isolation switch.
1. IP65 design,waterproof,anti dust and anti ultraviolet.
2. Strict test for high and low temperature,used widely/
3. The simple installation, the simplified system wiring, the convenient wiring.
4. The box body is made of cold rolled steel and other metal materials.
5. Used for single crystal silicon solar modules, poly crystalline silicon solar modules, thin film solar modules. Current rating of the photostatic fuse, circuit breaker, load isolation switch is modified.
