PHILIPS Xitanium 100W 0.7A 230V Y-sXt IP42 Gen 3 401080 phillips led 100W 700ma 220V 230V 240V for Road Lights

Share on:

Price:RUB 1,422.83
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

Product Description

Product Overview

LED-based light sources are an excellent solution for outdoor environment. They are long-lasting and require low maintenance. However, to get the best out of the LEDs, these light sources require highly reliable and efficient LED Drivers. The new Philips Xitanium Fixed Output and Dimmable (1-10V) LED Outdoor Drivers are specifically designed to deliver reliable performance and protection while meeting the strict performance, approbation and application requirements.

Benefits.

Reliability

•Robust design; capable of withstanding harsh outdoor conditions.
•Long lifetime and high survival rate.
•Superior thermal management suitable for outdoor application.
•Backed by 5 year warranty from a company you can trust.

Affordable
•Component integration in advanced IC enables cost effective design.
•Proven robustness & reliability secure the lowest luminaire maintenance over time.

Easy to use
•Extreme compact size. fitting with varied luminaires.
•Easy to design-in based on the good thermal management and extra EMI margin

Features.

•Proven robustness and reliable electronic driver design.
•Achieving highest efficiencies based on advance technology.
•Long lifetime; 50k hrs @Tc max.
•Extreme compact size, fitting with varied and critical luminaires.
•Suitable for Class I isolated luminaires.
•Authorized certificate: ENEC, CB, CE and CCC.

Application.

•Road and street lighting
•Area and flood lighting
•Tunnel lighting
•High-bay lighting

Datasheet

Electrical Input data

Specification item
Value
Unit
Condition
Nominal Input Voltage
220...240
Vac
Input Voltage AC
202...254
Vac
Performance range
Nominal Input Frequency
50...60
Hz
Input Frequency AC
47...63
Hz
Maximum permissible range
Nominal Input Current
0.52...0.48
A
220V...240V at full load
Maximum Input Current
0.55
A
At 202V
Nominal Input Power
115
W
At 230V at full load
Power Factor
≥0.95
At 230V at full load
Total Harmonic Distortion
≤10
%
At 230V at full load
Efficiency
90
%
At 230V at full load

Electrical Output data

Specification item
Value
Unit
Condition
Regulation Method
Constant Current
Output Voltage
64...143
Vdc
Output Voltage Max
220
Vdc
Peak voltage at open circuit
Output Current
700
mA
Performance range
Output Current Tolerance
±5
%
At max. output current
Output Current Ripple LF
5
%
Ripple = peak / average, at<1kHz
Output Power
100
W
At full load
Galvanic Isolation
Yes
Basic; 2U+1000V

Electrical Data Control Input

Specification item
Value
Unit
Condition
Control Method
N/A
V
Digital Interface
N/A
According 2.0 specifications
Mains Control
N/A
Can be configured via MultiOne
Time-based Integrated Control
N/A
Can be configured via MultiOne
Dimming Range
N/A
%

Operational Temperature and Humidity

Specification item
Value
Unit
Condition
Ambient Temperature
-40...+55
°C
Tcase Maximum
80
°C
Measured at Tc-point
Tcase Life
70
°C
Measured at Tc-point
Tcase Cut-Off
85
°C
Power to LEDs is reduced

Lifetime

Specification item
Value
Unit
Condition
Lifetime
100,000
Hours
At Tcase Life; Survival rate = 90%

Programmable Features

Specification item
Value
Remark
Condition
Adjustable Output Current (AOC)
N/A
Default Output Current = xxx mA
See Design-In Guide
LED Module Temperature Derating (MTP)
N/A
Constant Lumen Output (CLO)
N/A
DC Emergency Dimming (DCEmDIM)
N/A
Corridor Mode
N/A
Energy Metering
N/A
Diagnostics
N/A

Features

Specification item
Value
Remark
Condition
Open Circuit Protection
Yes
Short Circuit Protection
Yes
Automatic Recovery
Over Power Protection
Yes
Automatic Recovery
Hot Wiring
N/A
Suitable for fixtures with Protection Class
Class I

Surge Capability

Specification item
Value
Unit
Condition
Mains Surge Capability Differential Mode
4
KV
L-N,2Ohm
Mains Surge Capability Common Mode
4
KV
L/N-GND,2Ohm

Dimensions

Specification item
Value
Unit
Condition
Length overall
168
mm
Width overall
60
mm
Height overall
38
mm
Mounting Holes Distance
153
mm
Mounting Holes Width
43
mm
Mounting Holes Size
5
mm
For M4 with max head diameter of 10mm
Weight
586
g
Packing & Delivery
Packaging
Size
26*22*14CM
Weight
12kg



Packaging Details
Led Drivers and modules: Philips original carton packing with MOQ.(usually 10pcs or 12pcs in one carton.)
Led Light: Philips original carton packing(usually 1pcs in one carton)
Customize shipping packing (eg Composite wooden pallet, cardboard pallets and composite wooden cases package) are available at additional cost.
Our Service

We have 7x24 service, all emails and message will be responded in 4 hours.

Certifications

Approval Marks: CE / ENEC / CB / CCC
