FTTH MINI CATV Optical Receiver Fiber Node 1550nm

Share on:

Price:RUB 428.34 - RUB 506.22
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

FTTH MINI CATV Optical Receiver Fiber Node 1550nm



Product Description



OR16 Series Optical receiver is a home-based optical receiver for FTTH (fiber to the home) network optical fiber access terminal, in order to achieve analog or digital signal. The machine uses low-power optical detectors, GaAs and AGC technology to meet the needs of FTTH CATV reception. A variety of functional products in the application, slightly different.



Advantages



♦ High-quality Aluminum shell, through-hole design on both sides, good heat dissipation;
♦ RF channel full GaAs low noise amplifier. Digital signal minimum to meet -18dBm receiver, analog signal minimum to meet -10dBm receiver;
♦ With AGC function (AGC range can be customized);
♦ Anti-high-frequency surge protection device GaAs amplifier tube;
♦ Low-power design, the use of high-efficiency switching power supply to ensure that the power of high reliability and high stability. Overall power consumption is only 2W, with optical detection circuit;
♦ SC / APC & SC / PC & FC / APC & FC / PC optical connector options, male or female RF interface;
♦ Multi-level lightning protection device (TVS transient suppression diode), lightning protection system, to ensure the safe operation of equipment







Detailed Images






Index





ItemUnitParamterSupplement
Optical wavelength  nm1260~1620
1540~1560(WF)
1310nm,1490nm(WD)
Optical input range(dBm)                 0~-10Analog TV
0~-18Digital TV
Output return loss   (dB)≥45
BandwidthMHz47~862/1000
FlatnessdB±0.75
RF output level  (dBuv)≥80Pin:-9~0dBm
AGC control range  (dBm)0~-9
AGC characterdB≤±0.5Pin:-9~0dBm
ATT(dB)0-20MGC
Output return loss    (dB)≥1447-862MHz
Output impendance     (Ω)75
CNRdB≥51Pin=-2dBm
CTBdB≥61Pin=-2dBm
CSOdB≥60Pin=-2dBm
Power supplyV+5VDC
Power consumption    W≤3+5VDC,250mA
Operating temperature (℃)-20~+60
Dimensionmm112*106*28







Product Diagram

 OR16-3

Note: The actual number of RF output ports can be customized according to customer needs 1 or 2.



 Production process






Packaging & Shipping



10pcs OR18 FTTH optical receiver are packed in one box and 100pcs are packed in one outer carton, carton size is 310*242*83mm. The carton are suitable for all kinds of transportation, like international couier, by Air or by Sea. If the bulk order with large quantity, we can customize the carton with your logo for you.
