Automatic small type travel adjustable tablet pill capsule chewing gum chocolate liquid blister packing machine

Share on:


Price:RUB 307,152.00
Price in USD:Details

Quantity:

Add to Cart
  • add to wishlist

Product Overview

Description


Product Description




Model

DPB-88

Cutting Frequency (Times/min)

Al-Al: 6-20 times/min

Al-plastic: 10-35 times/min

Max. Production Capacity (Blister/h)

Al-Al: 1200 (According to standard plate 80×57)

Al-plastic: 2100 (According to standard plate 80×57)

Max. Forming Area and Depth (mm)

Al-Al: 80× 90×14

Al-plastic: 80×115×14(max depth can enlarge)

Travel Range (mm)

20-100 (Can be customized)

Air Pressure (Mpa)

0.4-0.6

Standard Plate (mm)

80×57 (Can be customized)

Total Power

380V/220V 50Hz 1.8kw

Main Motor Power (kw)

0.75

PVC Rigid Sheet (mm)

0.15-0.5×120

PTP Aluminum Foil (mm)

0.02-0.035×120

Dialysis Paper (mm)

50-100g×120

Mould Cooling

Tap Water or Circulating Water

Overall Dimensions (mm)

1400×460×950 (L×W×H )

Weight (kg)

450

Cutting Frequency (Times/min)

Al-Al: 6-20 times/min

Al-plastic: 10-35 times/min

Max. Production Capacity (Blister/h)

Al-Al: 1200 (According to standard plate 80×57)

Al-plastic: 2100 (According to standard plate 80×57)

Max. Forming Area and Depth (mm)

Al-Al: 80× 90×14

Al-plastic: 80×115×14(max depth can enlarge)

Travel Range (mm)

20-100 (Can be customized)

Air Pressure (Mpa)

0.4-0.6

Standard Plate (mm)

80×57 (Can be customized)

Total Power

380V/220V 50Hz 1.8kw

Main Motor Power (kw)

0.75

PVC Rigid Sheet (mm)

0.15-0.5×120

PTP Aluminum Foil (mm)

0.02-0.035×120

Dialysis Paper (mm)

50-100g×120

Mould Cooling

Tap Water or Circulating Water

Overall Dimensions (mm)

1700×560×1410(L×W×H)

Weight (kg)

500



Model

DPB-140

Cutting Frequency (Times/min)

Al-Al: 15-35 times/min

Al-plastic: 15-40 times/min

Max. Production Capacity (Blister/h)

Al-Al: 4200 (According to standard plate 80×57)

Al-plastic: 4800 (According to standard plate 80×57)

Max. Forming Area and Depth (mm)

Al-Al: 120× 100×20

Al-plastic: 130×110×26(max depth can enlarge)

Travel Range (mm)

20-120 (Can be customized)

Air Pressure (Mpa)

0.6-0.8

Standard Plate (mm)

80×57 (Can be customized)

Total Power

380V/220V 50Hz 5.2kw

Main Motor Power (kw)

1.5

PVC Rigid Sheet (mm)

0.15-0.5×140

PTP Aluminum Foil (mm)

0.02-0.035×140

Dialysis Paper (mm)

50-100g×140

Mould Cooling

Tap Water or Circulating Water

Overall Dimensions (mm)

2300×650×1615 (L×W×H )

Weight (kg)

900

Mould Cooling

Tap Water or Circulating Water

Overall Dimensions (mm)

2300×560×1410(L×W×H)



Model

DPB-250

Cutting Frequency (Times/min)

Al-Al: 15-30 times/min

Al-plastic: 15-35 times/min

Max. Production Capacity (Blister/h)

Al-Al: 8400 (According to standard plate 80×57)

Al-plastic: 9600 (According to standard plate 80×57)

Max. Forming Area and Depth (mm)

Al-Al: 230× 140×20

Al-plastic: 240×150×26(max depth can enlarge)

Travel Range (mm)

20-160 (Can be customized)

Air Pressure (Mpa)

0.6-0.8

Standard Plate (mm)

80×57 (Can be customized)

Total Power

380V/220V 50Hz 5.2kw

Main Motor Power (kw)

1.5

PVC Rigid Sheet (mm)

0.15-0.5×140

PTP Aluminum Foil (mm)

0.02-0.035×140

Dialysis Paper (mm)

50-100g×140

Mould Cooling

Tap Water or Circulating Water

Overall Dimensions (mm)

3000×730×1600 (L×W×H )

Weight (kg)

1600

Mould Cooling

Tap Water or Circulating Water

Applying:

It is suitable for capsule, tablet, honey pill, candy, liquid (ointment), paste as well as irregular shape Al-al Al-plastic and paper-plastic composite sealing packing in pharmacy, healthcare, food, cosmetics, medical equipment industry etc.

Features:

With manipulator towing and adjustable travel range, it can be suited for blister packing of various sizes.

Flat plate structure can pack special shape products, such as: elliptic shape, square shape, triangle shape, liquid, paste and syringe etc.

The whole procedure of feeding, forming, heat-sealing, impressing, batch number printing and cutting is accomplished automatically and continuously. The machine is small in size, with frequency inverter and ease of operation.

With touch screen operation,make the machine operation easy




 -221606477668(1)Blister packing machinedpb-260-1 (2)





                                                                                          DPB-88




                                                                                       DPB-140




                                                                                      DPB-250

blister packing machine 12
