electrospinning rotating drum collector for electrospinning for the nanofiber electrospinning system

Product Description

 TN-ESDC-80 is an 80 mm Dia. x 200 mm L stainless steel drum collector with oscillation and rotation speed control console for the nanofiber electrospinning system. In this setup, the nanofibers are winded in the form of aligned nonwoven membrane on a rotating drum. This method provides a relatively high production rate compared to the plate collector method.



Specifications

Features

Drum collector with adjustable rotation speed and digital speed display

Speed adjustable oscillation fixture for holding multiple liquid ejection needles

Compact design enables flexibility

Compatible with Argon gas environment

Input Power

24V DC

Drum Collector

Rotation speed: 0 - 450 rpm adjustable

Frontward and backward rotation

Speed accuracy: +/- 5 rpm

Drum size: 80 mm Dia. x 200 mm L

Optional drum with sizes of 30 or 50mm Dia. can be ordered

Oscillation Fixture



Syringe needle holder to mount up to 7 needles (7 slots of 12 mm Dia.)

Two adjustable positions limit sensors to control the fixture movement distance

Syringe needle head suggested having 100-200mm distance with collector drum

Fixture movement distance: 160 – 330 mm adjustable

The syringe needle is not included in the standard package.

Stage Dimensions

480 mm L x 480 mm W x 300 mm H

Warranty

One-year limited warranty with lifetime suppor

Shipping Weight

40 lbs
