#SuperSeptember zlp 630 suspended platform/ zlp630 suspended platform aluminum



Product Description



A.Description of suspended platform



zlp630 suspended platform is the latest products developed by RUIBIAO,with the features like more stable than elevator when start/stop,which greatly enhance the security and the service life of hoist and steel wire rope.The product has won the National hightech patent certificate.

zlp suspended platform is a new decorating machinery, which can replace the traditional scaffold and is mainly used in decorating, cleaning and maintenance of external walls of high buildings, such as cement coating, wall brick coating, painting, glass installing, ship building and repairing, big vessels, bridges, dams, chimneys, etc. Using Balance suspended platform can reduce work intensity and raise work efficiency.

zlp 630 suspended platform/ zlp630 suspended platform aluminum

B.Parameter of suspended platform


NameTechnical parameter
ModelZLP500ZLP630ZLP800ZLP1000
Rated load500Kg630Kg800Kg1000Kg
Lifting speed9-11m/min9-11m/min8-10m/min8-10m/min
Platform Dimension (2.5m*2)*0.69m*1.18m(2m*3)*0.69m*1.18m(2.5m*3)*0.69m*1.18m(2.5m*4)*0.69m*1.18m
Lifting Height100 m/328ft100 m/328ft100 m/328ft100 m/328ft
Cable100 m/328ft100 m/328ft100 m/328ft100 m/328ft
Steel ropeD:8.3mm     4*31SW+FC-8.3D:8.3mm     4*31SW+FC-8.3D:8.3/8.6mm 4*31SW+FC-8.3/8.6D:8.6/9.1mm 4*31SW+FC-8.6/9.1
HoistPower1.5KW1.5KW1.8KW2.2KW/3.0KW
 Voltage(A)

380V/220V/50HZ/

3PHASE

380V/220V/50HZ/

3PHASE

380V/220V/50HZ/

3PHASE

380V/220V/50HZ/

3PHASE

Voltage(B)220V/60HZ/1PHASE220V/60HZ/1PHASE220V/60HZ/1PHASE220V/60HZ/1PHASE

Safety lock

Permission force of impactLSB30:30KNLSB30:30KNLSB30:30KNLSB30:30KN
Locking Cable Angle3°~8°3°~8°3°~8°3°~8°
Suspension mechanismFront beam overhang1.12-1.7m/3.7-5.6ft1.12-1.7m/3.7-5.6ft1.12-1.7m/3.7-5.6ft1.12-1.7m/3.7-5.6ft
Counterweight1000kg1000kg1000kg1000kg
Working height0-200m/0-656ft0-200m/0-656ft0-200m/0-656ft0-200m/0-656ft



C.Main models of suspended platform

 zlp 630 suspended platform/ zlp630 suspended platform aluminum

ZLP500 galvanized/aluminum alloy suspended platform

 Power: 1.5kw*2  220v/380v/415v

Lift Platform size:2-12m

Rated load: 500kg

 zlp 630 suspended platform/ zlp630 suspended platform aluminum

ZLP630 galvanized/aluminum alloy suspended platform
Power: 1.5kw*2  220v/380v/415v  Lift Platform size:2-12m  Rated load: 630kg

 zlp 630 suspended platform/ zlp630 suspended platform aluminum

ZLP800/1000 galvanized/aluminum alloy suspended platform

Power:1.8/2.2kw/3kw*2 220v/380v/415v

Lift Platform size:2-12m  Rated load: 800kg/1000kg





D. suspended platform

suspended platform is mainly conmposed by suspension mechanism, lifting hoistsafety lockelectric control boxlifting platform.

Its structure is reasonable and easy to operate. It can be make-up and break-out according to the actual need. The suspended platform is mainly used for refurbishment, decoration, cleaning and maintenance of high construction building zlp 630 suspended platform/ zlp630 suspended platform aluminum



E.suspended platform schematic diagram

zlp 630 suspended platform/ zlp630 suspended platform aluminum

F. suspended platform packing & delivery

  • Experienced packer and forklift
  • Standard export packaging
  • Professional freight forwarder partner
  • 1*20' container 10 sets with counterweight
  • 1*40' container 14 sets with counterweight

zlp 630 suspended platform/ zlp630 suspended platform aluminum







zlp 630 suspended platform/ zlp630 suspended platform aluminum

RUIBIAO company profile

Shanghai Ruibiao Construction Machinery Co., Ltd. is located the modern international trade center, Shanghai city. The factory is built in an area of 20,000m3 and specializes in developing and manufacturing suspended platform, Building Maintenance Units and aerial work lift platform for work at heights. With its strong design team, advanced production and test equipment, exceptional after-sale service system and providing customers with solutions for aerial work at heights through the most advanced technological means.

The company has become China's leading manufacturer of aerial work equipment. It has also participated in preparing China’s suspended platform and Building Maintenance Unit National Standard.

zlp 630 suspended platform/ zlp630 suspended platform aluminum







zlp 630 suspended platform/ zlp630 suspended platform aluminum



RUIBIAO project and solution

Ruibiao brand suspended platform has been exported to more than 10 counteries around the world, such as Spain, Bulgaria, Colombia, America, Dubai, Singapore etc.
