2 or 4 Intel® Xeon® Scalable Processors of up to 205W
Memory
32 DDR4 DIMM slots, up to 2,666 MT/s; supports up to 1 TB with RDIMMs, and up to 2 TB with LRDIMMs
Note: The version with support for up to 4 TB LRDIMMs is planned for release in December 2017
Internal Storage
Supports the following hard drive configuration options:
8 x 2.5-inch SAS/SATA HDDs on the front, requiring one SAS RAID controller card
25 x 2.5-inch SAS/SATA HDDs on the front, requiring one SAS RAID controller card
8 x 2.5-inch NVMe SSDs and 16 x 2.5-inch SAS/SATA HDDs on the front
Note: The version with support for NVMe SSDs is planned for release in December 2017
RAID Support
Supports RAID 0, 1, 5, 6, 10, 50, or 60; supports a supercapacitor for cache power-off protection
Supports functions such as RAID state transition and RAID configuration memory
Network Ports
2 x 10 GE + 2 x GE LOM ports
PCIe Expansion
Up to 9 PCIe slots, 3 of which are built-in card slots and the other 6 external card slots:
− 3 x8 slots for 3 HHHL PCIe 3.0 x16 standard cards
− 1 x8 slot for 1 FHHL PCIe 3.0 x16 standard card
− 5 x8 slots for 5 HHHL PCIe 3.0 x8 standard cards
The PCIe expansion slots fully support Huawei proprietary PCIe SSD cards, which bolster I/O performance for applications such as searching, caching, and download services
Fan Modules
4 hot-swappable fan modules, providing protection against single-fan failures
Power Supply Units
2 hot-swappable PSUs, with support for redundancy. The PSUs support the following rated power:
1,500W AC Platinum PSUs:
1,000W (100V to 127V AC input)
1,500W (200V to 240V AC input)
1,500W (190V to 300V DC input)
Operating Temperature
5°C to 45°C (41°F to 113°F), compliant with ASHRAE Classes A3 and A4
