bluetooth 5.0 tag person tracking ibeacon push button beacon

Share on:

Price:RUB 523.72
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description




             About Beacon D15N
The UFO beacon D15N is a new generation beacon that loaded Bluetooth 5.0 hardware platform, hiddenpush button and MiniBeacon Plus intelligence software.

D15N UFO beacon advertises standard iBeacon and Eddystone (UID,URL,TLM) simultaneously. The user can configure D15N UFO beacon via configuration app BeaconSET+ as well.
About push button
The push button can be defined to advertise different data to meet different application by click, double-click and triple-click.
For example, the single click can be used to the panic / emergency / SOS button. For more functions, please refer to the configuration instruction.



Features


- Advertise iBeacon & Eddystone simultaneously

- Bluetooth® 5.0 chipset nRF52 series

- The max. 50 meters advertising distance

- Housing case with key-chain hole

- Push button for emergency using

Config APP

BeaconSET+




Details Images
                     Gift package
                     Small size


             Battery replaceable


Item
Value
Remarks
Case color
White
Other colors can be customized
Battery model
CR2025
1pc CR2025 coin battery, 150mAh, 3.0V
Operation Voltage
1.8-3.6V
DC
Transmission Circuit
10.5mA (Max.)
Tested at 0dBm
Transmission power
50 meters
Maximum
Antenna
50ohm
On board / PCB Antenna
Net Weight
7.0g
with battery but without package
Size
Ø 35 x 8.2 mm
Null
Product Usage




- Asset tracking
- Indoor location
- Personnel tracking





- Activity monitoring

Work with gateway
Our Service

- Print your logo on the top of iBeacon;
- Programm your firmware into Beacon device;
- Pre-configure the value of parameter before the shippment;
- PCB can be customized if needed;
- Package can be customized if required;
- Prototyping the casing and mold tool design and injection service.

Related Products

       BLE WiFi Gateway                                 Card Beacon                        Waterproof Beacon                      Long range Beacon
Packing & Delivery
Our Company

Founded in 2007, Minew has been engaged in IoT (Internet of Things) field more than 10 years and is keeping updated
to the market demand all along.
We are an ISO9001/ISO14001/OHSA18001 certified manufacturer focusing on products such as 2.4GHz BLE related products. We focus on
designing and manufacturing many different high quality and low cost IoT hardware. Product line includes:

1. BLE ibeacon/eddystone
2. BLE sensor
3. BLE wifi gateway
4. BLE module
5. BLE tracker
6. Electronic shelf label


FAQ

Do you provide the technical support to the developers?
Re: SURE. The following technical data and documents will be provided to developers.
1. SDK 2. API 3. Demo APP 4. Configuration APP 5. Instructions

Can I develop my own app?
Re: Yes, SDK will be sent for your own app development.

Do you have SDK or the source code?
Re: Yes, we will provide you after sample was arrived.

How to upgrade the firmware via over-the-air?
Pls refer to the file "OAD instructions.pdf".Minew sales will provide you the document.
