Output: Biphasic Truncated exponential
Energy Sequence(adult ): 150/150/200(Default) .150/200/200 . 200/200/200
Energy Sequence(Pediatric): 50/70/85(Default) . 70/70/85 . 70/85/85 . 85/85/85
Charge Time: Less than 10 sec. to 200J
Analysis Time: 9 sec.
Less than 30 seconds is the maximum time from the initiation of rhythm analysis to readiness for maximum Energy discharge after 15
Less than 35seconds is the maximum time from initially switching power on to readiness for maximum Energy discharge after 15
Audible Prompts 19 audible prompts
Self-test battery, main processor, memory and program, ECG acquisition system, and defibrillator.
Visual Prompts LED/LCD
Controls: six buttons - On/Off, Shock, and 4 software-configurable buttons
Output Energy Accuracy: ±15% into any impedance from 25 to 175Ω
Non-rechargeable Battery : 15V d.c. 2.8Ah , Capacity 100 discharges at 200 Joules or 120 discharges at 150 Joules
