Product Overview

Description

_01

Specification

Cable ties strength reference standard
No. Specification Length (L) Width (W) Bundle Diameter (E) Tensile Strength
inch mm mm mm KGS LBS N
1 A3(2.4)×80 3″ 80 2.4 2-16 8 18 80
2 A3(2.4)×200 8″ 200 2.4 3-50 8 18 80
3 A3(2.4)×100 4″ 100 2.4 2-22 8 18 80
4 A3(2.5)×100 4″ 100 2.5 2-22 10 23 100
5 A3(2.5)×120 5″ 120 2.5 2-30 10 23 100
6 A3(2.5)×150 6″ 150 2.5 2-35 10 23 100
7 A3(2.5)×200 8″ 200 2.5 3-50 10 23 100
8 A4(3.5)×150 6″ 150 3.5 3-35 16 36 160
9 A4(3.5)×200 8″ 200 3.5 3-50 18 41 180
10 A4(3.5)×250 10″ 250 3.5 3-65 18 41 180
11 A4(3.6)×120 5″ 120 3.6 3-30 18 41 180
12 A4(3.6)×150 6″ 150 3.6 3-35 18 41 180
13 A4(3.6)×200 8″ 200 3.6 3-50 20 45 200
14 A4(3.6)×250 10″ 250 3.6 3-65 20 45 200
15 A4(3.6)×300 12″ 300 3.6 3-80 20 45 200
16 A5(4.6)×120 5″ 120 4.6 3-24 20 45 200
17 A5(4.6)×150 6″ 150 4.6 3-35 20 45 200
18 A5(4.6)×200 8″ 200 4.6 3-50 25 55 240
20 A5(4.6)×250 10″ 250 4.6 3-65 25 55 240
22 A5(4.6)×300 12″ 300 4.6 3-82 25 55 240
24 A5(4.6)×350 14″ 350 4.6 3-90 25 55 240
25 A5(4.6)×370 14.5″ 370 4.6 3-100 25 55 240
26 A5(4.6)×380 15″ 380 4.6 3-102 25 55 240
27 A5(4.6)×400 16″ 400 4.6 3-105 25 55 240
28 A5(4.6)×430 17″ 430 4.6 3-115 25 55 240
29 A5(4.6)×450 18″ 450 4.6 3-130 25 55 240
30 A5(4.6)×500 20″ 500 4.6 3-150 25 55 240
31 A5(4.8)×120 5″ 120 4.8 3-24 22 48 220
32 A5(4.8)×190 7.5″ 190 4.8 3-40 25 55 240
33 A5(4.8)×200 8″ 200 4.8 3-50 25 55 240
34 A8(7.2)×200 8″ 200 7.2 3-50 45 100 450
35 A8(7.2)×250 10″ 250 7.2 4-63 45 100 450
36 A8(7.2)×300 12″ 300 7.2 4-82 45 100 450
37 A8(7.2)×350 14″ 350 7.2 4-90 45 100 450
38 A8(7.2)×380 15″ 380 7.2 4-102 45 100 450
39 A8(7.2)×400 16″ 400 7.2 4-105 45 100 450
40 A8(7.2)×450 18″ 450 7.2 4-118 45 100 450
41 A8(7.2)×500 20″ 500 7.2 4-150 45 100 450
42 A10(8.8)×400 16″ 400 8.8 10-105 65 144 650
43 A10(8.8)×450 18″ 450 8.8 10-125 65 144 650
44 A10(8.8)×500 20″ 500 8.8 12-150 65 144 650
45 A10(8.8)×550 22″ 550 8.8 12-160 80 178 800
46 A10(8.8)×600 24″ 600 8.8 12-175 80 178 800
47 A10(8.8)×650 26″ 650 8.8 12-190 80 178 800
48 A10(8.8)×720 28.3″ 720 8.8 12-190 80 178 800
49 A10(8.8)×760 30″ 760 8.8 12-190 80 178 800
50 A10(8.8)×800 32″ 800 8.8 12-230 80 178 800
51 A10(8.8)×920 36.2″ 920 8.8 12-265 80 178 800
52 A10(8.8)×1000 40″ 1000 8.8 12-300 80 178 800
53 A10(8.8)×1200 48″ 1200 8.8 12-370 80 178 800
