Aluminium Pipe Cutting Machine

Share on:


Price:RUB 149,055.00
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

Product Description





It is adapted for sawing aluminum extrusion material, aluminum doors and windows, radiating rib, wooden material, water pipes and sound faceplate.

It is suitable for cutting various materials, such as aluminum, brass, heat sink, PVC, plastic steel, Bakelite, acrylic plastic, honeycomb board, wood and other non-ferrous metals.



Feature

1. When operating the machine, just step on the foot switch, the machine will automatically clamp and cut, easy to operate.

2. Hidden blade up and down can be very safe work.

3. Vertical slide way for advance and retreat blade up and down.

4. The cutting feed is stable, the service life of the cutter is long, and the sawing accuracy is high.

5. Cooling liquid and lubricating liquid spray out automatically during cutting to ensure smooth cutting surface and prolong the service life of saw blade.

6. The cutting feed is driven by the cylinder so the cutting speed is extremely stable.

7. The saw blade Angle is fixed and the cutting precision is improved.

8. The shelves have a positioning panel, which is more convenient to cut the material.



Technical parameter

Model

JR-S455

Cutting Angle

90 °

Cutting Capacity(HxW)

120*300mm

Spindle Speed

2800-3300 R.P.M.

Saw Blade Size

φ355-455mm

Table Area

645*668mm

Table Height From Floor

850mm

Motor Power

4 kw

Air Pressure

4-6 kg/cm²

Conveyor Length (opt.)

According to customers requirements

Voltage

380V or customized

Feed Mode

Up and down

Weight

300 kg



Company Information

.jpg

Our Services



1. Warranty period: We guarantee machine quality for one year, during this year, if spare parts of the machine were damaged, we can send the component to the customer by DHL, TNT freely.

2. Our company can send our engineer to the customer’s factory install, commission and training freely. The customer has to provide the double trip tickets, food and accommodation for our engineer. The customer also can send the engineer to our company to learn the operation and maintains freely.

3. Our company provide the service for the customer forever, if the customer need operation help, you can contact us by Skype, Email and Telephone at any time.
