Product Description

New chemical mixing equipment liquid mix agitator price



YHAE500S-H 001

The application of lab mixer
The lab mixer adopts structure compact series-excited type miniature high speed motor drive for the Low to medium and high viscosity liquid mixing, crushing particle materials in liquid medium shear emulsification.The dispersing emulsifier is widely used in the lab experimentation, to test or develop new product. With small size, high quality ,easy to operate.

Main features of lab mixer

1) The drive system is stable and reliable
2) The dispersing emulsifier with high shear effect

3) Can handle a wide range of viscosity
4) Stepless speed regulation
5) With five different specifications of the work head
6) Speed digital display



Technical specifications of lab mixer

Laboratory Dispersing EmulsifierYHAE500S-H 70G
Rated voltageAC220 V
Rated frequency50/60 Hz
Input power850 W
Output power500 W
Rated torque178.0 N.cm
Working systemS1 ((continuous)
Operation control modeCombination control knob
Speed adjustment range2000~14000 rpm
Speed control typestepless
Timing control range1~1000 min
Speed digital display×10 rpm  LED
Dynamic speed detection functionYes
Speed memory functionYes
Overload protection functionYes
Working head maximum torque172.0 N.cm
The maximum linear velocity of the rotor18 m/s
Work head materialStainless steel 304 #
Working head diameterΦ70 mm
Working head min/max immersion liquid height50/236 mm
Stator standard configuration5 mm2    20mm2   50mm2
Treatment capacity (H2O)500~40000 ml
Maximum processing viscosity8000 mPa.s
Allow the ambient temperature≤ 40 ℃
Relative humidity≤ 80 %
Overall dimensions215×310×720 mm
Machine weight9.2 kg   (Gross Weight: 11.0 kg)
