Embedded 1D 2D Barcode Scanner High Temperature Resistance QR Code Scanner

Feature and advantage

1. Support 2D/1D barcode and support screen and paper barcode

2. 1GHz 32 bits CPU,high speed for data processing.

3. Temperature resistance can reach 105℃,long service life.

4. Small size, powerful and easy to integrate in industrial equipment.

5. It supports 2nd development,multiple development language,also SDK.

6. Highly cost-effective,highly sales volume.

7. We can offer the FFC flat cable for free and 12pin connector if client needed.

8. We can offer test board and USB cable for sample testing.



Detail Parameters

Item Parameter Name Parameter Value
Product Info. Product name Embedded 1D 2D Barcode Scanner High Temperature Resistance QR Code Scanner
Model HW-1258
Application POS,Sacnner gun,PDA,ticket machine etc.embedded module
Performance Light source 620nm Visible Red Diode,white LED for illumination
Imaging Sensor CMOS
Imaging resolution ≥5mil
Resolution Rate 648(horizon)*488(vertical)
Typical DOF Code 128(6mil) 30-100mm       Code 128(20mil)50-250mm
QR code(5mil)30-60mm          QR code(20mil)40-220mm
Performance may be impacted by bar code quality and environmental conditions
Sensor field angle Level 66°,Vertical 50°
Scanning Angle Rotate 360°,Tilt ±40°,Defection ±60°
Minimum Contrast ≥30%
Trigger mode Manual Mode,Auto mode,continuous mode,POS mode etc.
Language  Support multi-languages
Deconding Capacity 1D/2D paper and screen code
1D:Code 39,Code11, Code 128, UPC-A,UPC-E,UPC-E1,EAN-8,EAN-13,EAN-128,UCC128,ISBN/ISSN,Code32,Code39 full ASCII, Code 93, Interleaved 2 of 5,GS1,Matrix 2 of 5, Industrial 2 of 5,UK/Plessey etc.
2D:QR, Data Matrix, PDF417 Aztec Code etc.
Electronic Interface TTL232&USB
Connection 12pin FPC/FFC Flexible cable
Power voltage 3.3VDC
Operating current <190mA
Standby Current <48mA
Structure Scanner size 21.2*16.9*11.2mm
weight 5g
cable length 10cm FPC/FFC
Reliability Storage temperature -40℃~105℃
Operating temperature -10℃~105℃
Operating humidity 5%~95%(non-condensing)
Storage humidity 5%~95%(non-condensing)
