Great Easy Westcode Operation Thyristor

Product Description



KN341A24

Asymmetric thyristor Applications



Features:

  . All Diffused Structure

   . Center Amplifying Gate Configuration

   . Blocking capabilty up to 2000 volts

   . Guaranteed Maximum Turn-Off Time

   . High dV/dt Capability

   . Pressure Assembled Device



ELECTRICAL CHARACTERISTICS AND RATING



Blocking - Off State

VRRM (1)

VDRM (1)

VRSM (1)

10

2400/2800

10

       VRRM = Repetitive peak reverse voltage

       VDRM = Repetitive peak off state voltage

       VRSM = Non repetitive peak reverse voltage (2)



Repetitive peak reverse leakage and off state leakage

IRRM / IDRM





5 mA

40 mA (3)

Critical rate of voltage rise (4)

dV/dt

1000 V/mse





Conducting - on state



Parameter

Symbol

Min.

Max.

Typ.

Units

Conditions

Average value of on-state current

IT(AV)



341



A

Sinewave,180o conduction,Tc =85oC

RMS value of on-state current

ITRMS



1040



A

Nominal value

Peak one cycle surge

(non repetitive) current



ITSM



-



5700



A



A

8.3 msec (60Hz), sinusoidal wave-

shape, 180o conduction, Tj = 125 oC

10.0 msec (50Hz), sinusoidal wave-

shape, 180o conduction, Tj = 125 oC

I square t

I2t



1.5



KA2s

8.3 msec and 10.0 msec

Latching current

IL



-



mA

VD = 24 V; RL= 12 ohms

Holding current

IH



1000



mA

VD = 24 V; I = 2.5 A

Peak on-state voltage

VTM



2.45



V

ITM = 1000 A; Duty cycle £ 0.01%



Critical rate of rise of on-state

current (5, 6)

di/dt



2000



A/ms

Switching from VDRM £ 1000 V,

non-repetitive

Critical rate of rise of on-state

current (6)

di/dt



1000



A/ms

Switching from VDRM £ 1000 V
