High Stiffness Steel Scaffolding Concrete Construction Formwork For Slab,Wall,Column,Roof,Beam,etc.Guangzhou Manufacture

Share on:

Price:RUB 298.67 - RUB 2,239.96
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

Formwork 1.Q235 formwork 2.Waterproof construction formwork

3.Smooth surface formwork 4.Perforated concrete construction formwork



High Stiffness Steel Concrete Construction Formwork

for Slab,Wall, Column,Roof,Beam,etc. Guangzhou Manufacture

 41515
Construction formwork Description


1. AJ formwork is hot sale products in current concrete construction market due to its long life span, exact size, flat edge, beatiiful painting smooth surface and high capacity.

2. AJ steel formwork system include flat formwork panel, external corner formwork, internal corner formwork and connect corner formwork and formwork accessories.

3. The material of steel formwork is Q235 steel panel sheet, which cutted in exact size by automatical machines.

4. We use CO2 arc welding technique which is done by very skilled welding workers.

5. Our popular size can fit the most building size, some special size also can be made for you.

6. The thickness of steel surface panel and ribs will be different according to your building concrete situation.

our regular thickness is 4mm.

Construction formwork Trade Information


Name

steel construction formwork for building

Type

flat formwork, corner formwork, circular formwork

Brand

AJ brand

Place of Origin

Made in Guangzhou, China

Material

Q235 carbon steel

Length

1800,1500,1200,900,750,600,450mm, or as specialized

Width

600,500,450,300,250,200,150mm, or as specialized

Thickness

3mm/4mm/5mm

Width of ribs

50mm

Surface treatment

High protected painted, or as specialized

Color

Regular color is red, other color also available

Welding technique

CO2 arc welding

Certification

SGS,BV,EN12810

MOQ

100pcs

Packing

1*20ft: 20tons

Production capacity

100 tons per day



Construction Formwork Specification
Steel Formwork (21)
Flat steel formwork
CodeLength(mm)Width(mm)Height(mm)Thickness(mm)Surface treatWeight(kg)
FF1800-6001800600503painted40.98
FF1800-4501800450503painted31.26
FF1800-3001800300503painted21.55
FF1800-2001800200503painted14.37
FF1500-6001500600503painted34.27
FF1500-4501500450503painted26.14
FF1500-3001500300503painted18.02
FF1500-2001500200503painted12.01
FF1200-6001200600503painted27.55
FF1200-4501200450503painted21.02
FF1200-3001200300503painted14.48
FF1200-2001200200503painted9.66

Corner Angle Formwork
CodeLength(mm)Flange height(mm)Thickness(mm)Surface treatWeight(kg)
FC1800180050*503painted4.45
FC1500150050*503painted3.71
FC1200120050*503painted2.9 7



External Corner Formwork
CodeLength(mm)Flange height(mm)Thickness(mm)Surface TreatmentWeight(kg)
FEX18001800100*1003painted16.35
FEX15001500100*1003painted13.76
FEX12001200100*1003painted11.17



Internal Corner Formwork
CodeLength(mm)Flange Height(mm)Thickness(mm)Surface Treatment(mm)Weight(kg)
FIN18001800100*1003painted15.21
FIN15001500100*1003painted12.76
FIN12001200100*1003painted10.31



Construction Formwork Sample

 steel formwork(13)



steel formwork(19)



Steel construction formwork clamps are used to lock the formwork together





steel formwork loading picture (1)







 Steel Formwork(166)

ABOUT US



Established in 1999Guangzhou Safety Scaffolding Co., Ltdhas become the leading manufacturer and

supplier of scaffolding and formwork system. Relying on top quality and high credit standing, our brand "AJ

scaffolding has wohigh praise from customers around the world.



AJ Group consists of three main factories(Guangzhou Safety Scaffolding Co., LtdDongguan AJ Scaffolding

Co., Ltd, and Hebei Safety Scaffolding Co., Ltdand covers an area of 30,000 sqm which daily output is

more than 100 tons. With experienced technicians and advanced machinery, we are able to manufacture

various types of scaffolding and formwork systems as per customer's designs or samples.



Our main products include quicklock scaffolding, frame scaffolding, kwikstage scaffolding, cuplock scaffolding,

ringlock scaffolding, adjustable shoring props, steel formworks, formwork clamps, steel pipes & couplers,

adjustable U head jack & jack base, and other scaffolding accessories. In recent years, our product line also

involves part of construction machines and tools.



Over 17years, our products have been exported to more than 100countries mainly in Africa, South America, Asia,

and Middle East. AJ doesn't only manufacturand sell world-class productsbut also provides design skills and

 technical advice that helps contractors build their projects in the most secure and economicawayAJ ialways

engaged in developing new technology and improving customer service to meechanging demands from

different markets.



Please be free to contact us for furtheinformationLook forward to cooperating with you!

Why us?



Experience: 17 years in scaffolding manufacturing.7 years in exporting.

Cooperation: more than 100countries ( up to December.2015, the Number is 103.)

Quality: Certified by SGS, BV, EN12810, Local Test Report.

Delivery: own factory in Guangzhou and Dongguan, 20 Minutes from Huangpu Port/Guangzhou Port.

Price: Moderate, Reasonable.

Service: Friendly and Responsible, no matter before or after cooperation.



Welcome to Visit Our Factory to Get More Information About Our concrete construction Formwork.
