LGK-40 Inverter Portable Air Plasma Cutter

Share on:


Price:RUB 3,934.46 - RUB 9,442.71
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

Product Description

 LGK-M Series Inverter Air Plasma Cutter



-Small volume, light weight, simple installation, easy operation;

-Good cutting property, high cutting efficiency;

-Continuously adjustable output current, excellent operating property;



Model

LGK-40M

LGK-60M









Parameters

Input voltage

One-phase AC 220V±15% 50/60Hz

Three-phase AC 380V±15%  50/60Hz

Rated input power (A)

22.1

12

Floating voltage (V)

220

280

Output current adjustment (A)

20-40

20-60

Rated output voltage (V)

96

104

Duty cycle (%)

35

35

No load loss (W)

40

50

Efficiency (%)

85

85

Power factor

0.93

0.93

Type of arc striking

Contact striking

Contact striking

Suggested compressing pressure(MPa)

4.5

4.5

Class of insulation

F

F

Grade of casing protection

IP21S

IP21S

Overall dimensions(W*D*H)mm

155*295*375

205*360*480

Weight (kg)

8

13



-weld stainless steel,carbon steel,cast iron ,steel and other alloy material

-Theproducts are widely used in pretrochemical ,medicine,electrical power,apermaking,cement,metallurgy and mining

industry
