Солнечный инвертор Suntree DC сглаживатель перепадов напряжения переменного тока 3-полюсный 1000 В освещения разрядник Защита от перенапряжения устройство для защиты солнечной системы от перенапряжения переменного тока

Сохранить в закладки:


Цена:*
Стоимость в USD:Показать (текущая цена)

Количество:

  • В избранное

Описание и отзывы

Характеристики



Product Description




Packing & Delivery


To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.




Company Profile








Specification


Type
SUP2H-PV
Pole
3P
2P
Uoc max (V DC)
1000
800
Uc (V DC)
1000
800
ln(8/20)us(kA)
20
20
lmax(8/20)us(kA)
40
40
Up (kV)
2
3.8
Maximum working voltage
250VAC/30VDC
Maximum working current
1A(250VAC)


Wiring capacity
Hard wire
4-25
Flexible wire
4-16
Striping length
10
Terminal screwa
M5


Torque(Nm)
Main circuit
3.5
Remote singal control
0.25


Protection class
All profile
IP40
Connection port
IP20
Installation environment
No obvious shock and cibration


FAQ


Q: How can i trust you and your company ?
A: Suntree is a group company, we have 6 subcompanies. Have cooperation with LS, EKF the world-class companies. Our company over
500 employees, products pass CE,IEC,TUV,SAA, RCM, ROHS certificates.

Q:How long is your products warranty ?

A: The warranty period of our products is 2 Years.

Q:How about inspection?
A: We have the whole inspection system from raw material to end products include Transient test, delay test,mechanical life test
and so on.

Q:What is the service offered by company?
A: We have the professional enginer team which can design and develop the mold to arrive different customer requirement.
We also have the sales team to offer good service from pre-sale to after-sale.
