Wecon 10,2 дюймовый IoT HMI с удаленным доступом и бесплатным облаком для удаленного загрузки и отладки PLC

Сохранить в закладки:


Цена:*
Стоимость в USD:Показать (текущая цена)

Количество:

  • В избранное

Описание и отзывы

Характеристики


IoT HMI-PI3000ig








































































































































































































Main



OS



Linux 4.4.0 QT based



Processor



Cortex A35 1.2GHz



Display



Size



10.2"



Screen



TFT



Resolution



1024*600



Color



16,000k colors



Brightness (cd/m2)



350



Backlight



LED



Backlight Lifetime



50,000 hours



Touch Panel



High precision four-wire resistive



Storage



    Memory



128 MB



Flash



128 MB



SD Card Slot



YES



USB Port



USB2.0 Host + USB2.0 Client



RTC



Real-time clock



 --



Calendar



Yes



I/O Port



COM1



CN1:RS422/RS485
CN2:RS232
CN3:RS485



COM2



--



COM3



--



Ethernet



x1



CANopen



 --



Power



Rated Power



< 15W



Power Voltage



DC 24V



Input range



DC 12 ~ 28V



Shell Color



Grey



Enclosure



Shell Material



PC+ABS



Overall Size (mm)



272.0W*191.0H*41.5D



Mounting Size (mm)



260.0W*179.0H



Mounting Method



Panel Mount



Weight (Kg)



1.02



Environment



Working Temperature



30 ~ 70°C



Storage Temperature



-10 ~ 60°C



Humidity



10 ~ 90%RH (Non-condensing)



Vibration Resistance



10 ~ 25 Hz (X, Y, Z direction 2G/30 minutes)



Cooling



Air Cooling



Software



Programming



PIStudio



Remote Access



 --



Email Alarm



 --



IP Camera



 --



Audio Output



 --



Video Player



 --




Data Tool



Yes



Certificates



IP Code



IP65 (Front panel)



CE



CE Marked


FCC

FCC Class A






3070igPI3000ig(3)


3102ig
