Product Description

Glonass Low Noise Signal Amplifier Booster is a single stage gain block in a small form factor that covers the GLONASS frequencies. The device features 30 or 40dB gain and a noise figure less than 1.5dB. Since the product consumes less than 25mA, the device can be placed in line with the receiver antenna and can be powered by the receiver's antenna voltage output.

Economy Manual Shielded Boxes Enclosure rf signal shielding test 800MHz-3.5GHz for telecom and wireless signal testing
\t
Product Name
\t
28dB Gain Glonass Signal Amplifier
\t
Model
\t
SA28
\t
In-Line way
\t
Passive type ; Active Type
\t
Gain
\t
28±1.0
\t
Noise Figure(dB)
\t
≤2.0
\t
Standing-wave Ratio (VSWR)
\t
≤2.0
\t
Impedance(Ω)
\t
50
\t
Voltage(V)
\t
5 V for passive one; 9~ 24 for active one
\t
Working current( ma)
\t
≤70 for both passive and active
\t
Connector Type
\t
SMA-K ; N-K
\t
Storage Temperature
\t
-55~+85
\t
Operating Temperature(℃)
\t
-40~+80
\t
Dimensions(mm)
\t
SMA: 51 x 41 x 16; N: 50 x 41 x 18.5mm
\t
Unit Weight
\t
SMA: 0.10kg ; N : 0.15 kg;
