2. Operating environment 2.1 Work system: 24-hour continuous work 2.2 Installation Bar: Indoor Installation (preferably Centralized Pipeline Exhaust System) 2.3 Supply Voltage: 3-phase 380V, 50HZ; Voltage fluctuation range (+10%) 2.4 Compressed air pressure: 0.5-0.55 Mpa 2.5 Oxygen Pressure: 0.6-0.9 Mpa 2.6 Nitrogen Pressure: 0.4-0.6 Mpa 2.7 Gas welding, gas pressure: 0.08-0.10Mpa 2.8 Relative humidity of working environment: 30-98% 2.9 Welding with gas flux or without flux
Specification
Welding Material and Products
Brass and copper pipe welding
Welding Form
Flame welding
Infiltration depth
6~10mm
The specific process flow is as follows: (1) Manual feeding. when the feeding is finished, turn the table to the next station. (2) check whether there is any product on the tooling. If there is any product, the lower station will work normally; If there is no product, then all the processing mechanisms on the following stations have no action. after the test, turn the rotary table to the next station. * if the product is detected, the first welding gun will preheat product 1, and the welding gun will be returned after completion. will be transferred to the next station.
(4) The second welding gun welds the product 2, and the welding gun moves up and down. At the same time, the wire feeding mechanism swings left and right to send the wire to the next position after welding. (5) Nitrogen-filled protection will be applied after each welding. (6) there will be air cooling at two stations and secondary air cooling (water cooling or air cooling can be selected according to customer requirements). (7) after natural cooling, turn the rotary table to the next station. (8) Two products can be welded at one time. (9) double wire feeding mechanism is adopted for each welding gun to make the solder more uniform.
Main Technical Specifications of Equipment 1) the brazing machine is in the form of "six-equal rotary table", which controls the flow and pressure of gas and oxygen in the gas circuit system, so as to ensure the constant gas output from the nozzle of the torch and ensure the stability of product quality. The equipment is multi-station structure, mainly composed of fuselage, fixture, preheating system, welding system, cooling device, automatic nitrogen filling system, gas pressure regulating control box, electric control system and protective device. Air and water cooling systems can be installed according to customer needs.
2) The wire feeding device uses disc brazing filler wire, and the brazing filler wire feeding process is stable. The filler metal feeding speed and time can be adjusted arbitrarily, and the wire feeding length can be adjusted. The wire feeder is a servo motor accelerator and decelerator. There are also two handwheels on the wire feeder, which can adjust the height and direction according to the requirements, and can be easily adjusted when replacing the products.
3) the two welding guns also use stepping motor to adjust up and down, while the front and back of the welding gun can also beadjusted.The upper and lower limit switches are set in the welding gun to prevent the collision and scraping of the gun caused by operation errors. and the use of servo motor to carry out welding gun swing.
.......
14) adopt multi-station flame brazing and welding method. Manually put the matched pipe fitting into the positioning fixture. The equipment adopts automatic wire feeding. after the workpiece welding is completed, wait for the completion of cold, manual feeding.
15) the equipment is equipped with three-party protective door and smoke cover, and 400mm smoke exhaust interface is reserved.
Centralized training The training contents include: safety operation rules, on-site operation practice, maintenance theory and practice, theoretical knowledge of electrical and hydraulic systems, analysis and troubleshooting of common faults, etc. When equipment enters the stage of installation and commissioning, Party A may send personnel to participate in commissioning. Party B trains operation and maintenance personnel for Party A to understand the structure, principle and performance of the equipment as soon as possible. At the same time, it is conducive to the inspection and supervision of the equipment and to ensure product quality.
After installation and debugging of the equipment by party a, party b shall provide free training for the operation and maintenance personnel of the users.
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
Q: Which product is your best-seller? A: Digital auto flame brazing machine
Q: Do youhave customized service? A: Yes, We have professors in our R&D team, if you have any special demand, just contact us for best solutions.
Q: How can you guarantee the product's quality ? A: We have very strict quality control system, with 8 years' experience
Q: How long will be the delivery time? A: Usually 7-15 days after received the prepayment.
Q: Are you trading company or manufacturer ? A: We are a manufacturer.
Q: What about you sales service? A: 7*24 hours online
