QP112 Fire Alarm System Control Panel single zone
- Category: >>>
- Supplier: HORING LIH INDUSTRIAL CO. LTD.
Share on (10000000922374):
Product Overview
Description
QP112 Made in Taiwan QP112 Fire Alarm System Control Panel
Characteristics
- Removable front board for easy maintenance.
- Easy-to-clean front board is able to avoid dirt attached.
- High luminance and long life span LED.
- Build-in 24V power and battery charger.
- Independent visual & audible indication for zone open/short fault.
- Independent visual & audible indication for AC power & battery fault.
- Visual & audible indication for sounder short circuit fault.
- Buzzer silence with 3-mode operation feature.
- Short circuit = Alarm feature (selected by JUMPER, applicable for manual call point w/o resistance)
- Accurate supervision circuit for battery.
Specifications
| Model | QP112 |
| Power | 220V AC, 50/60Hz *Others also available |
| Battery Capacity | 24V / 1.2Ah |
| Max. Output Current | 1A |
| # of heat detectors connected | No limit *Except electronic-type |
| # of smoke detectors connected | 30/zone *Horing Lih manufactured |
| End of Line Resistor | 4.7 kΩ |
| Material | 1.2mm steel plate |
| Dimensions (H x W x D) | 203 x 272 x 71 |
Approval
How to Order
Company Information
Horing Lih Industrial Co., Ltd.
4F., No. 18, Lane 327, Chung Shan Road, Sec. 2,
Zhonghe District 235, New Taipei City, Taiwan
Tel : +886 2 2248-7599 Fax : +886 2 2240-7752
Horing Lih has designed high quality safety and protection products for a wide range of fire alarm systems including detectors, control panels, fire alarm components and many more. The addition of our state-of-the-art manufacturing facility enables us to maintain quality assurance as we continue to expand throughout the whole world. With our distributors serving over 50 countries, we have established a world-wide distribution network.
Horing Lih has been in the Fire Alarm market for 32 years and we have built a fine reputation based on our customers' feedback. We continually bring new products into the market because HoringLih knows what customers need.
Horing Lih has a long-term devotion to the fire alarm business with only one purpose - "We are concerned about people's life."
