Product Overview

Description



Product Description




Introduction
Apart from Aluminum, Copper is the most widely used material for making heat sinks, because properties of copper make it suitable
for the purpose.Micro-porous copper foam is like an open cell structure, with an extraordinarily large number of interconnected
pores distributed uniformly throughout the base copper material.
Advantage:
1. Copper foam has great function of conducting heat and electricity, which can be used as the electrode substrate of lithium ion
battery or fuel cell or Nickel zinc battery and electric double layer capacitor electrode material.
2. The copper foam can be also used as Heat sink materials, heat absorption materials, chemical catalyst carrier, electromagnetic
shielding materials, filtration materials, damping materials, battery electrode materials, deadening, high-grade decorative materials.


Type
Open cell
Purity
> 99%
Form
Sheet or Roll, depending on size & thickness
Cell Size (PPI)
10-150PPI, as per request
Thickness
Standard: 1-30mm Extra thin (<1mm) / Extra thick (>30mm) can be customized as request
Size & Shape
Standard: 500*500mm/ 200*300mm; can be made in different shape as per request
Porosity
95%-98%
Open Cell Rate
≥98 %
Volume Density
>0.1g/cm3, as per request
Surface Density
200-2500 g/m ^2, as per request
Thermal Conductivity (Theoretical)
>6W/M.K
Mechanical Strength (Theoretical)
≥2.5MPa
Tensile Strength (Theoretical)
5-18MPa


80um*200mm*300mm
0.2mm*200mm*300mm
0.3mm*200mm*300mm
0.5mm to 1.7mm*200mm*300mm
2mm*200mm*300mm
3 to 4mm*200mm*300mm
5mm*200mm*300mm
6mm*200mm*300mm
8mm*200mm*300mm
10mm*200mm*300mm
10 to 40mm*200mm*300mm
The size can be customized






Company Profile






Cooperative Partner




Customers Feedback




Package & Transport




FAQ




Q1：What is the pore size on the foam and what is the PPI range？
A：100um<pore size<10mm, PPI range is 5ppi-500ppi.

Q2：Do you accept credit card payment?
A：We accept any payment method, credit card, bank transfer, Paypal, etc.

Q3：Can you customize the size and shape？
A：Yes, we accept customization, not only the size and shape, but also PPI or porosity and pore size.

Q4：Can I place one small order for first time to test the quality?
A：Small order are also welcomed.

Q5：Can I visit your factory?
A：Your are welcomed to visit our factory，and we offer free hotel and free car.
