High Pressure Heat Exchanger Tubes/ Finned Copper Tubes/Copper Pipe Heat Exchanger
- Category: >>>
- Supplier: SHREE EXTRUSIONS LIMITED
Share on (10000001905864):
Product Overview
Description
"High Pressure Heat Exchanger Tubes/ Finned Copper Tubes/Copper Pipe Heat Exchanger"
Product Description
| Product Description |
C70600 , Copper nickel offers excellent corrosion resistance, especially in marine salt water environments. The main, wrought coppernickel alloys chosen for sea water service contain 10 or 30 percent nickel. They also have important additions of iron and manganese which are necessary to maintain good corrosion resistance
Typical Applications:
- AUTOMOTIVE: Power Steering Tube, Brake Lines
- CONSUMER: Screw Lamp Bases
- INDUSTRIAL: Condenser Plates, Condensers, Weld Torch Tips, Heat Exchanger Tubes, Valve Bodies, Evaporator Tubes, Pressure Vessels, Distiller Tubes, Pump Impellers for Oil Refining, Ferrules, Evaporators
- MARINE: Boat Hulls, Tube Sheet for Salt Water Service, Salt Water Pipe Fittings, Salt Water Piping Systems, Salt Water Piling Wrap, Hot Water Tanks, Salt Water Baffles, Propeller Sleeves, Ship Hulls, Water Hoses
- PLUMBING: Flanges
Equivalent Specifications
Chemical Composition
Physical Properties
Sizes Available
| SPECIFICATIONS | DESIGNATION |
|---|---|
| ISO | CuNi10Fe1Mn |
| Europen | CuNi10Fe1Mn |
| BS | CN 102 |
| JIS | C 7060 |
| Russian | MNZMo10-1-1 |
Chemical Composition
| Cu | Fe | Pb | Mn | Ni | Zn | |
|---|---|---|---|---|---|---|
| Min/Max | Rem | 1.0 - 1.8 | 0.05 | 1 | 9.0 - 11.0 | 1 |
| Nominals | 88.6000 | 1.4000 | - | - | 10.0000 | - |
Physical Properties
| Coefficient Of Thermal Expansion | 9.5 10−6Per °F (68-572 F) |
| Density | 0.323 Lb/In3 At 68 F |
| Electrical Conductivity | 9 %IACS @ 68 F |
| Electrical Resistivity | 115.0 Ohms-Cmil/Ft @ 68 F |
| Melting Point Liquid US | 2100 F |
| Melting Point Solid US | 2010 F |
| Modulas Of Elasticity In Tension | 18000 Ksi |
| Modulas Of Rigidity | 6800 Ksi |
| Specific Gravity | 8.94 |
| Specific Heat Capacity | 0.09 Btu/Lb/°F At 68 F |
| Thermal Conductivity | 26.0 BTU In/Hr.Ft2.°F @ 68 F |
Sizes Available
| HOLLOW RODS | Min Bore Size 20 Mm And Max OD 100 Mm |
| ROUND RODS/RODS | 8mm To 100 Mm |
| HEX | 10mm To 60mm |
| SQUARE | 10mm To 60mm |
| FLAT | 10mm Min Thickness And Max Width 120mm |
| BILLETS | Up To 200 Mm |
| INGOTS | AS Per Specification |
Company Information
| About Us |
Established in the year 1989, Shree Extrusions Limited has earned a prestigious position as a manufacturer, supplier and exporter of Extruded Profile in Non Ferrous Metals. Our never-ending list of products includes Aluminum Bronze Rods, Nickel Silver Wire, Aluminum Bronze, Copper Alloy and Brass Rod. Moreover, we also offer Brass Wire for Leaded Ball Pen Tip, Nickel Silver Wire for Ball Pen Tip, Brass Wire, Aluminum Silicon Bronze Rod and Naval Brass. We have been able to earn the accolades of many renowned organizations such as Govt. of India Ministry Defense, Hindustan Shipyard Ltd, Naval Dockyard and Ship Building Centre owing to the international level of quality.
Though, our products are acclaimed worldwide but we have built a strong client base in Asian Countries. Our well established infrastructural setup is located in Jamnagar, Gujrat. The use of latest technologies such as Spectrometers (spark as well as ERF X-Ray Fluorescence) and Electronic & Computerized UTM makes us offer world-class quality products. The entire range products offered by us are valued for its excellent performance, longer service life, economical prices and high tensile strength. These are mostly used in architectural fittings, hardware, electric components, forged components, industrial valves, defense components and pump rods. We fabricate our range of products using high-grade raw material such as virgin non ferrous metals, scraps and turning.
Our mentor, Shri Radheshyam L. Kabra has more than 35 years of experience in the domain, enabling him to proficiently manage our organizational activities. Under his able guidance, we have been able to achieve enviable market credibility.
Our Vision:
“Backed by top notch technology and proven track record in various industries of the world Shree Extrusions Ltd., vision future needs & supplies wide range of products.”
Prouct Podrtfolio:
We have emerged as a top-notch company engaged in manufacturing, supplying and exporting of aluminium extruded profiles in non ferrous alloys. Our entire range includes Brass Wire for Leaded Ball Pen Tip, Nickel Silver Wire for Ball Pen Tip, Brass Wire, Aluminum Silicon Bronze Rod and Naval Brass. We even offer, Aluminum Bronze Rods, Nickel Silver Wire, Aluminum Bronze, Copper Alloy and Brass Rod. These are fabricated using high-grade raw material such as virgin, scrap and turning and can be customized as per the requirements of our customers. All our products are widely used in architectural fittings, hardware, electric components, forged components, industrial valves, defense components and pump rods. The range of extruded non ferrous metals available with us is preferred over others due the following features:
- Corrosion resistance
- Enhanced durability
- High conductivity ( Brass Rod)
- Optimum fluidity (Brass Ingot & Billet)
- Ability to function with perfection even in high temperatures
- Excellent tolerance(Mechanical Brass Part)
Product Range
| Product Range |
ljjlk
Areas of Application
| Industrial Applications |
Certifications
Certifications & Achievements |
We offer finest range of extruded non ferrous metals & metal profiles, which are appreciated all through the Asian countries. Due to hard-work and premium quality products, we have earned the certificates & approvals from the following prestigious organizations:
- Govt. of India Ministry Defense
- Our Laboratory has been approved by SQAE(AR), Mumbai
- Garden Reach Shipbuilders & Engineers Limited, Calcutta
- Material Organization Mumbai, Vishakhapatanam, Khambhalia
- Hindustan Shipyard Ltd., Vishakhapatanam
- Mazagon Dock Limited, Mumbai, India
- Naval Dockyard, Mumbai
- Ship Building Centre, Vishakhapatanam
Quality Assurance
Our constant endeavor, to be a niche player in our work, sets us above from others. Each of our products go through stringent checks and controls at various stages. The cornerstone of our success lies in a proactive management & excellent product quality. We use high-grade raw material sourced from authentic vendors of the market. Our quality-testing lab is approved by SQAE (AR), Mumbai and is has modern equipment and facilities that ensure flawlessness of our products. Our facilities consist of:
Repeat orders from our clients speak volumes about our consistency in quality & performance. Our team of quality controllers conduct stringent quality tests & control mechanisms based on the following parameters:
Owing to our state-of-the-art production & quality assessment facility, we have been able to complete our bulk orders within the committed time period and without any compromise on quality. We have been able to build a strong client base in Asian countries and have attained huge market credibility.
- Spectrometers (spark as well as ERF X-Ray Fluorescence)
- Electronic and Computerized UTM
- Impact Testing Machines with photography
- Microscopy with photography
Repeat orders from our clients speak volumes about our consistency in quality & performance. Our team of quality controllers conduct stringent quality tests & control mechanisms based on the following parameters:
- Raw material used
- Preciseness
- Corrosion resistance
- Durability
Owing to our state-of-the-art production & quality assessment facility, we have been able to complete our bulk orders within the committed time period and without any compromise on quality. We have been able to build a strong client base in Asian countries and have attained huge market credibility.
Contact Us
| Contact Us |
 | Shree Extrusions Limited
|
