Transformer Sitas 4AM6142 8JD40 0FA0 Phases 1 Screw/Tab Connection Current Transformer
Transformer Sitas 4AM6142-8JD40-0FA0 Phases 1 Screw/Tab Connection Current Transformer

Transformer Sitas 4AM6142 8JD40 0FA0 Phases 1 Screw/Tab Connection Current Transformer

Share on (10000002746129):


Price:$4,330.64 - $4,681.77

Quantity:


Product Overview

Description





Product Description



TRANSFORMER SITAS; PHASES:1; PN/PN(S6)(KVA):1,6 /7,3; UPRI(V):400-230+/-15; USEC(V):2X115; ISEC(A):6,96-13,91; F(HZ):50...60; VECTOR GR./SHIELD WNG.:II0 /0; TA/ISOKL:40 /B; IP00; TYPE OF TERMINALS: SCREW/TAB CONNECTION INSTALLATION:SCREW; EN 61558-2-1, -2-2, -2-4 >UL/CSA-RECOGNIZED< >CONTROL CIRCUIT TRANSFORMER< >ISOLATION-TRANSFORMER<






Siemens are the intelligent choice for compact automation solutions with extended communication options and integrated technology functions. The latest SIMATIC controller-portfolio offers machine builders both PLC- and PC-based solutions for implementing innovative machine concepts.


Specification


Operating apparent power rated value
1 600
Efficiency
0.96
Short-term vector power
7 300
Relative short-circuit voltage
2.1
Phase number of the outputs
1
Protection class IP
IP00
Height
0.164m
Width
0.176m
