1200C 1400C 1600C 1700C 1800C Lab Small Mini Box Type Muffle Furnace for Battery Making
- Category: >>>
- Supplier: Quanzhou Lineng Machinery And Equipment Co. Ltd.
Share on (10000003312133):
Product Overview
Description
1200C 1400C 1600C High Temperature Laboratory Box-Type Muffle Furnace with Carbon Steel Layer and 30 Segment PID Controller
LN muffle furnace uses double carbon steel layer shell and 30 segement PID control. The furnace consists of high purity alumina polycrystalline fiber brick and high quality heating element. This furnace equips with air cooling system, which makes temperature cool and rise quickly. It is an ideal tool for materials annealing and sintering , composition analysis, quality testing, ashing in colleage lab, research institutes, etc..
Standard Features
1200°C,1400°C,1700°C maximum operating temperature;
High purity fibrous alumina insulation for maximum energy saving;
Double layer steel structure with air cooling fan to keep furnace's exteriors safe to touch;
Safty interlock will automatic power off the furnace when door is opened;
PID automatic control via current limiting phase angle fired the resistor, e.g. SC R(Silicon Controlled Rectifier);
Power control with 30 segments programmable.
Accessories (specify these at time of order)
Standard Accessories
Thermal gloves | Crucible Tongs | Thermocouple | Crucibles | Furnace Door Block | User Manual
Optional
Different chamber size for your choose;
LCD touch screen control for choose
Program software to connect computer for choose.
Content may be subject to modifications or corrections
Standard Features
1200°C,1400°C,1700°C maximum operating temperature;
High purity fibrous alumina insulation for maximum energy saving;
Double layer steel structure with air cooling fan to keep furnace's exteriors safe to touch;
Safty interlock will automatic power off the furnace when door is opened;
PID automatic control via current limiting phase angle fired the resistor, e.g. SC R(Silicon Controlled Rectifier);
Power control with 30 segments programmable.
Accessories (specify these at time of order)
Standard Accessories
Thermal gloves | Crucible Tongs | Thermocouple | Crucibles | Furnace Door Block | User Manual
Optional
Different chamber size for your choose;
LCD touch screen control for choose
Program software to connect computer for choose.
Content may be subject to modifications or corrections
Model Number | SX2-12TP | SX2-14TP | SX2-17TP | ||
Max. temp | 1200℃ | 1400℃ | 1700℃ | ||
Continuous working temp | ≦1100°C | ≦1300°C | ≦1600°C | ||
Chamber size | 100x100x100mm, 200x150x150mm, 300x200x200mm, 400x300x300mm, or customize as your requirement | ||||
Heating element | Resistance wire with Mo | SiC heating rod | MoSi2 heating rod | ||
Temp control | 30 segments PID automatic control | 30 segments PID automatic control | |||
Thermal couple | K type | S type | B type | ||
Chamber material | High purity alumina polycrystalline fiber | Alumina Ceramic fiber | Ceramic fiber | ||
Heating rate | 0-30°C/min,suggest to be 15.C/min | 0-30°C/min,suggest to be 10.C/min | 0-30°C/min,suggest to be 5-10.C/min | ||
Thermal control accurancy | ±1°C | ||||
Temp uniformity | ±5°C | ||||
Power supply | AC 110-415V, 50/60HZ | ||||
Max. power | 1kw for 100*100*100mm; 2kw for 200*150*150mm; 6kw for 300*200*200mm; 9kw for 400*300*300mm | 2kw for 100*100*100mm; 4kw for 200*150*150mm 9kw for 300*200*200mm; 16kw for 400*300*300mm | 2kw for 100*100*100mm; 4kw for 200*150*150mm; 9kw for 300*200*200mm; 16kw for 400*300*300mm | ||
