100% PPS nonwoven interlining (Melting point of 285 C) aramid fiber
100% PPS nonwoven interlining (Melting point of 285 C) aramid fiber
100% PPS nonwoven interlining (Melting point of 285 C) aramid fiber
100% PPS nonwoven interlining (Melting point of 285 C) aramid fiber
100% PPS nonwoven interlining (Melting point of 285 C) aramid fiber

100% PPS nonwoven interlining (Melting point of 285 C) aramid fiber

Share on (10000003509621):


Price:

Quantity:


Product Overview

Description





Products Description




Polyphenylene Sulfide (PPS) is a high performance material with:

　☑Excellent resistance against both acids and alkalis
　☑Excellent heat resistance with melting point of 285 degrees C
　　 and can endure for constant use at 190 degrees C
　☑Not being hydrolyzed under steamy environments.








Superb heat resistance

Melting point(blue)：285℃
Service temperature(yellow)：190℃
※The temperature that a strength decrease
　 by 50% after 100, 000 hours processing..







Flame retardance


LOI:34
It has high self-extinguishing performance in the air (oxygen level:21%).


 Product Description
Item name
PS
Component
Polyphenylene Sulfide (PPS)100%
Weight
15g/㎡～150g/㎡
Thickness
30µm～320µm
Features
・ Heat resistance
・ Steam resistance
・ Chemical resistance
・ Thermal insulation
・ Flame resistance
Applications
Have been used for membrane backing fabric and get along with versatile casting polymers
such as PVDF, PES, PSF, PAN, PEI and Nylon.

 ・As a gas separation membrane support to select, separate, and recover
     various gases  such as CO2 and N2
・As a membrane support to be used for decolorization under high temperature
    and /or steamy environments

・ Cleaning the copier
・ MF / UF membrane base material for non-food applications
・Septum
・Protective filter








Examples of Hirose PPS Nonwovens




Grade
Basis Weight
(g/m2)
Thickness
(microns)
Density
(g/cm3)
Tensile Strength
MD (N/50mm)
Tensile Strength
CD (N/50mm)
Air Permeability
(cc/cm2/sec)
PS 15g
15.3
32
0.478
51.2
6.4
180.7
PS 20g A
19.8
71
0.279
61.2
18.3
184.7
PS 20g B
17.5
35
0.500
47.9
18.2
116.7
PS 40g A
38.2
101
0.378
51.7
27.6
62.9
PS 40g B
41.5
56
0.741
127.2
54.3
13.8
PS 60g A
60.5
151
0.400
135.9
65.5
33.5
PS 80g A
81.0
163
0.497
239.2
119.6
17.3
PS 80g B
80.1
107
0.749
272.0
129.9
4.4
PS 100g A
101.8
230
0.443
275.8
116.2
16.1
PS 100g B
100.5
123
0.817
272.9
188.8
1.8
PS 150g
152.1
318
0.478
320.4
146.5
10.2


Above data is actual figure for your reference, but not guaranteed values
