We will test the switches before shipping. All the switches are new and original
24 Port 40 Gigabit Ethernet Module Switch for N77-F324FQ-25 | |
VOQ buffer | 144 MB per module |
Jumbo frame support for bridged and routed packets | Up to 9216 bytes |
Forwarding performance | 1.44 bpps of Layer 2 and Layer 3 forwarding capacity for both IPv4 and IPv6 packets |
MAC address entries | 64,000 |
VLAN | 4096 simultaneous VLANs per VDC |
IPv4 entries | 64,000 |
IPv6 entries | 32,000 |
CoPP | Supported |
Physical dimensions | ● Occupies one I/O module slot in a 7700 platform chassis ● Dimensions: 1.75 x 15.9 x 21.8 in. (4.4 x 40.39 x 55.37 cm) ● Weight: 17 lb (7.7 kg) |
Environmental conditions | ● Operating temperature: 32 to 104°F (0 to 40°C) ● Operational relative humidity: 5 to 90%, noncondensing ● Storage temperature: -40 to 158°F (-40 to 70°C) ● Storage relative humidity: 5 to 95%, noncondensing |
Regulatory compliance | ● EMC compliance ● FCC Part 15 (CFR 47) (USA) Class A ● ICES-003 (Canada) Class A ● EN55022 (Europe) Class A ● CISPR22 (International) Class A ● AS/NZS CISPR22 (Australia and New Zealand) Class A ● VCCI (Japan) Class A ● KN22 (Korea) Class A ● CNS13438 (Taiwan) Class A ● CISPR24 ● EN55024 ● EN50082-1 ● EN61000-3-2 ● EN61000-3-3 ● EN61000-6-1 ● EN300 386 |
Environmental standards | ● NEBS criteria levels* ◦ SR-3580 NEBS Level 3 (GR-63-CORE and GR-1089-CORE) ● Verizon NEBS compliance* ◦ Telecommunications Carrier Group (TCG) Checklist ● Century Link NEBS requirements* ◦ Telecommunications Carrier Group (TCG) Checklist ● ATT NEBS requirements* ◦ ATT TP76200 level 3 ● ETSI* ◦ ETSI 300 019-2-1, Class 1.2 Storage ◦ ETSI 300 019-2-2, Class 2.3 Transportation ◦ ETSI 300 019-2-3, Class 3.2 Stationary Use * Validation in Progress |
Safety | ● UL/CSA/IEC/EN 60950-1 ● AS/NZS 60950 |
24 Port 40 Gigabit Ethernet Module Switch for N77-F324FQ-25
The Cisco Nexus 7000 Series Switches are the foundation of the Cisco® Unified Fabric solution. Designed to meet the requirements of mission-critical data centers, these switches deliver exceptional availability, outstanding scalability, and the proven and comprehensive Cisco NX-OS Software data center switching feature set.
The Cisco Nexus 7700 platform is the latest extension to the Cisco Nexus 7000 Series modular switches. With more than 83 terabits per second (Tbps) of overall switching capacity, the Cisco Nexus 7700 platform delivers the highest-capacity 10, 40, and 100 Gigabit Ethernet ports in the industry, with up to 768 native 10-Gbps ports, 384 40-Gbps ports, and 192 100-Gbps ports. This high system capacity is designed to meet the scalability requirements of the largest cloud environments.
The Cisco Nexus 7700 platform is the latest extension to the Cisco Nexus 7000 Series modular switches. With more than 83 terabits per second (Tbps) of overall switching capacity, the Cisco Nexus 7700 platform delivers the highest-capacity 10, 40, and 100 Gigabit Ethernet ports in the industry, with up to 768 native 10-Gbps ports, 384 40-Gbps ports, and 192 100-Gbps ports. This high system capacity is designed to meet the scalability requirements of the largest cloud environments.
Product Selling Points
Features and Benefits
● The 7700 F3-Series module is powered by the proven and comprehensive NX-OS feature set. This extremely comprehensive set of Layer 2 and Layer 3 functions makes this module excellent for data center networks, in which density, performance, and continuous system operation are critical.
● The 7700 F3-Series module is a critical enabler of Cisco FabricPath. With FabricPath, organizations can build resilient, flexible, and if needed, massively scalable Layer 2 networks. FabricPath protects enterprises’ investments by allowing existing spanning-tree-based deployments to be connected to a FabricPath network.
● The 7700 F3-Series module can be used in conjunction with the Cisco Nexus 2000 Series Fabric Extenders (FEX). The 2000 Series is designed to simplify data center architecture and operations by dramatically reducing the number of points of management.
● The 7700 F3-Series module supports port breakout. Up to 19 of the 24 physical ports on the module can be configured in breakout mode, each becoming 4 logical and independent 10 Gigabit Ethernet ports. This breakout mode can be configured at any time on any port (up to 19 ports) independently from configuration of other ports and without the need to reload the module. When 19 ports of the module are configured in breakout mode, the other 5 ports remain available for establishing 40 Gigabit Ethernet links. Copper or fiber breakout assemblies are required to enable the physical separation of 10-Gigabit channels.
● The 7700 F3-Series module delivers integrated Fibre Channel over Ethernet (FCoE), greatly simplifying the network infrastructure and reducing costs by enabling the deployment of unified data center fabrics to consolidate data center traffic onto a single, general-purpose, high-performance, highly available network. With the 7700 F3-Series module, FCoE can be deployed in director-class modular platforms for the access layer and core of converged networks.
● The 7700 F3-Series module provides support for wire-rate VXLAN, offering the architectural flexibility needed to expand cloud deployments with repeatable pods in different Layer 2 domains. VXLAN can also enable migration of virtual machines between servers across Layer 3 networks.
● The support for advanced data center interconnect (DCI) protocols such as Cisco OTV and VPLS makes the module excellent for helping customers simplify the extension of applications across geographically dispersed data center sites.
● The 7700 F3-Series module supports high-performance MPLS for 40 Gigabit Ethernet data center deployments.
● Support for Cisco LISP enables enterprises and service providers to simplify multihomed routing and facilitates scalable any-to-any WAN connectivity while supporting data center virtual machine mobility.
● The virtual device context (VDC) feature helps enable the virtualization of a single physical device in one
or more logical devices. Each provisioned logical device is configured and managed as if it were a separate physical device.
● The 7700 F3-Series module offers exceptional security with integrated hardware support for:
◦ Configurable Control-Plane Policing (CoPP), which protects the supervisor CPU from excessive traffic
◦ Access control list (ACL) counters and logging capability to provide deeper packet visibility
◦ Layer 2 to Layer 4 ACL for both IPv4 and IPv6 traffic
◦ Cisco TrustSec® technology and ACL processing for security group tags (SGTs)
● The 7700 F3-Series module is powered by the proven and comprehensive NX-OS feature set. This extremely comprehensive set of Layer 2 and Layer 3 functions makes this module excellent for data center networks, in which density, performance, and continuous system operation are critical.
● The 7700 F3-Series module is a critical enabler of Cisco FabricPath. With FabricPath, organizations can build resilient, flexible, and if needed, massively scalable Layer 2 networks. FabricPath protects enterprises’ investments by allowing existing spanning-tree-based deployments to be connected to a FabricPath network.
● The 7700 F3-Series module can be used in conjunction with the Cisco Nexus 2000 Series Fabric Extenders (FEX). The 2000 Series is designed to simplify data center architecture and operations by dramatically reducing the number of points of management.
● The 7700 F3-Series module supports port breakout. Up to 19 of the 24 physical ports on the module can be configured in breakout mode, each becoming 4 logical and independent 10 Gigabit Ethernet ports. This breakout mode can be configured at any time on any port (up to 19 ports) independently from configuration of other ports and without the need to reload the module. When 19 ports of the module are configured in breakout mode, the other 5 ports remain available for establishing 40 Gigabit Ethernet links. Copper or fiber breakout assemblies are required to enable the physical separation of 10-Gigabit channels.
● The 7700 F3-Series module delivers integrated Fibre Channel over Ethernet (FCoE), greatly simplifying the network infrastructure and reducing costs by enabling the deployment of unified data center fabrics to consolidate data center traffic onto a single, general-purpose, high-performance, highly available network. With the 7700 F3-Series module, FCoE can be deployed in director-class modular platforms for the access layer and core of converged networks.
● The 7700 F3-Series module provides support for wire-rate VXLAN, offering the architectural flexibility needed to expand cloud deployments with repeatable pods in different Layer 2 domains. VXLAN can also enable migration of virtual machines between servers across Layer 3 networks.
● The support for advanced data center interconnect (DCI) protocols such as Cisco OTV and VPLS makes the module excellent for helping customers simplify the extension of applications across geographically dispersed data center sites.
● The 7700 F3-Series module supports high-performance MPLS for 40 Gigabit Ethernet data center deployments.
● Support for Cisco LISP enables enterprises and service providers to simplify multihomed routing and facilitates scalable any-to-any WAN connectivity while supporting data center virtual machine mobility.
● The virtual device context (VDC) feature helps enable the virtualization of a single physical device in one
or more logical devices. Each provisioned logical device is configured and managed as if it were a separate physical device.
● The 7700 F3-Series module offers exceptional security with integrated hardware support for:
◦ Configurable Control-Plane Policing (CoPP), which protects the supervisor CPU from excessive traffic
◦ Access control list (ACL) counters and logging capability to provide deeper packet visibility
◦ Layer 2 to Layer 4 ACL for both IPv4 and IPv6 traffic
◦ Cisco TrustSec® technology and ACL processing for security group tags (SGTs)
