network optical switch S12516X AF internet switch
- Category: >>>
- Supplier: XWIFI INDUSTRIAL LIMITED
Share on (10000004358164):
Product Overview
Description
Details Images
Installation Instructions
We will test the switches before shipping. All the switches are new and original
network optical switch S12516X-AF internet switch | |
Switching capacity | 230.4T/1032Tbps |
Throughput | 115200Mpps |
MPU slots | 2 |
LPU slots | 16 |
Maximum power consumption | 19200W |
Dimensions (H x W x D) | 931 x 440 x 857 mm (21U) 36.7 x 17.3 x 33.7 in |
Switching fabric module slots | 6 |
MPU processor | Quad Core 1.2 GHz |
MPU Flash | 1 GB |
MPU Console Port | 1 |
IPv4 | Static routing, RIP, OSPF, IS-IS, and BGP4 VRRP, VRRP load balancing ECMP Policy-based routing Routing policy GRE, IPv4 in IPv4 tunneling |
MPLS VPN | P/PE function in accordance with RFC2547bis Three inter-AS MPLS VPN modes: Option 1, Option 2 and Option 3 Hierarchy of PE (HoPE) Multi-role host VPLS Distributed multicast VPN |
VXLAN | VXLAN L2 switching VXLAN L3 routing VXLAN VTEP IS-IS+ENDP distributed control plane MP-BGP+EVPN distributed control plane OpenFlow+Netconf centralized control plane |
Temperature | Operating temperature: 0°C to 40°C (32°F to 104°F) Storage temperature: -40°C to 70°C (-40°F to 158°F) |
The H3C S12500X-AF DataCenter Cloud Core Switch Series is designed for cloud services data centers. It provides the following features:
CLOS+ multi-grade multi-plane architecture
Industry’s highest performance core switch with 768 line-speed 40G/100G interface per chassis
Integration of IRF2 (Intelligent Resilient Framework version 2), and MDC (Multi-tenant Device Context) to
implement virtual resource pools
implement virtual resource pools
Distributed ingress buffers (200 ms) to accommodate burst traffic in data centers
Independent control, detection, and maintenance engines to implement 50ms failover and powerful control capabilities
The S12500X-AF switch series includes S12504X-AF, 12508X-AF and S12516X-AF, which meet various port density and performance requirements. The S12500X-AF switch series can work with H3C routers, switches, security devices, IMC, and H3Cloud to provide a wide variety solutions.
Product Selling Points
High Availability (HA)
Patented hot standby technology provides data backup and non-stop forwarding on the control plane and data plane. It improves
availability and performance,
eliminates single-point of failures, and ensures service continuity.
Patented hot standby technology provides data backup and non-stop forwarding on the control plane and data plane. It improves
availability and performance,
eliminates single-point of failures, and ensures service continuity.
Distribution
Multi-chassis link aggregation to enable load sharing and backup over multiple uplinks, improving redundancy and link utilization.
Multi-chassis link aggregation to enable load sharing and backup over multiple uplinks, improving redundancy and link utilization.
Easy Management
A single IP address to manage the whole IRF fabric, which simplifies device and topology management, improving operating efficiency, and lowering network maintenance cost.
A single IP address to manage the whole IRF fabric, which simplifies device and topology management, improving operating efficiency, and lowering network maintenance cost.
Company Profile
XWIFI company provides high-end data center switches from Huawei, applied to ISP & IDC, operating over 10 years. We are based in zhongguancun, Beijing. We aims to provide users with high-quality products and campus network solutions by integrating market advantages through efficient supply chains. We will initiate the second phase of our development strategy. Our company regards“ reasonable prices, efficient delivery time and good after-sales service” as our tenet. We hope to cooperate with more customers for mutual development and benefits. Our equipment are selling well all over the world and getting lots of best evaluation from customers. We are appreciated it if you can choose us and cooperated with us!
Product packaging
FAQ
1.How can i get the price?
-We usually quote within 24 hours after we get your inquiry (Except weekend and holidays). If you are very urgent to get the price, please email us or contact us in other ways so that we can offer you a quote.
-We usually quote within 24 hours after we get your inquiry (Except weekend and holidays). If you are very urgent to get the price, please email us or contact us in other ways so that we can offer you a quote.
2.Can I buy samples placing orders?
-Yes.Please feel free to contact us.
-Yes.Please feel free to contact us.
3.What is your lead time?
-It depends on the order quantity and the season you place the order. Usually we can ship within 7-15 days for small quantity, and about 30 days for large quantity.
-It depends on the order quantity and the season you place the order. Usually we can ship within 7-15 days for small quantity, and about 30 days for large quantity.
4.What is your payment term?
-T/T, Western Union, Money Gram, and Paypal. This is negotiable.
-T/T, Western Union, Money Gram, and Paypal. This is negotiable.
5.What is the shipping method?
-It could be shipped by sea, by air or by express (EMS, UPS, DHL, TNT, FEDEX and ect). Please confirm with us before placing orders.
-It could be shipped by sea, by air or by express (EMS, UPS, DHL, TNT, FEDEX and ect). Please confirm with us before placing orders.
6.How do you make our business long-term and good relationship?
-a. We keep good quality and competitive price to ensure our customers benefit;
-b. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
-a. We keep good quality and competitive price to ensure our customers benefit;
-b. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
