ROKTOOLS High Accuracy Thermocouple Thermometer Support K T and J 200~1370 degree Multi point calibration

Product Overview

Description



ROKTOOLS  High Accuracy Thermocouple Thermometer Support K T and J -200~1370 degree Multi-point calibration

INTH-1306A Choose A

INTH-1306B Choose B

Features

·  Support K, T and J thermocouples

·  Resolution up to 0.01℃

·  Factory accuracy ±(0.3%|t|+0.40)℃

·  Accuracy up to ±0.1℃ after point calibration

·  Measuring range -200~1370℃

·  Display temperature graph

·  Over-limit alarm function

·  Support 4 kinds of format files (INTH-1306B)

Description

INTH-1306A is an instrument used to measure temperature by applying the principle of thermocouple temperature measurement. Thanks to the high-precision circuit principle and high-precision reference source inside the instrument, coupled with accurate factory calibration, the resolution of the instrument reaches 0.01℃, and the factory precision reaches ±(0.3%|t|+0.40)℃.

INTH-1306A can display temperature change curve. This instrument also opens the point calibration function for users, and accurate multi-point calibration can greatly improve the measurement accuracy of the whole machine (the system composed of the host and the probe). This instrument supports the most commonly used K, T and J thermocouple probes. This compatibility with multiple types of probes expands the application fields of the instrument.

INTH-1306B adds the recording function on the basis of YET-610. YET-610L can record all the data during temperature measurement. The files generated by the recording can be viewed directly on this machine or on any device that supports reading U disk.

INTH-1306B also uses data space separation technology, so it can export files in a variety of different formats. Most importantly, the files stored in the instrument can be restored at any time and transferred to other devices. This backup measure effectively reduces the risk of accidental data loss by users.

·  Large dot matrix LCD screen, high-quality backlight

Application

·  Laboratory physical measurement and recording

·  Boiler equipment operation

·  Concrete pouring

·  Metal processing

·  Food

·  Medicine

·  Household

·  Industry, aerospace

·  Cold chain transportation

·  Car market

·  Livestock

·  Supermarket





Specification



Model	INTH-1306A	INTH-1306B
Channel	1
Record Function	No	Yes
Probe Type	Support K, T, J type thermocouple
Unit	℃,℉
Device Measuring Range	Type K: -200~1370℃    Package with K probe: -50~350℃ Type T: -200~400℃     Package with K probe: -40~350℃ Type J: -200~1200℃    Package with J probe: -40~750℃
Resolution	0.01℃ (-200.00℃~+999.99℃) 0.1℃  (+1000.0℃~+1370.0℃)
Accuracy	±(0.3%|t|+0.40)℃  up to ±0.1℃ after point calibration
Sample Rate	2 times/second
Calibration	Multi-point calibration
Storage Capacity	No	20000 groups of readings
Record Interval	No	1~86399 seconds adjustable
File Format	No	txt, csv, xls, dlg
Compatible System	No	Windows XP/Vista/7/8/10
Display	Dot matrix LCD screen with backlight
Operating Temperature	-10~50℃(non-condensing)
Stored Temperature	-20~60℃(without battery)
Power Supply Request	3pcs of 1.5V AAA alkaline batteries   3pcs of 1.2V AAA rechargeable batteries 5V USB (not recommended)
Battery Life	About 190 hours (conditions: instrument continues to work, the backlight is off, the battery capacity is 1200mAh, and the ambient temperature is 25℃)
Protection Class	IP52
Dimension	174*73*40mm
Weight	About 198g (excluding batteries and probes)
Warranty	12 months
