Type | SC-NH80-A | SC-NH100-A | SC-NH150-A | SC-NH200-A | ||||
Panel | Power | (80W+16W)/18V | (80W+16W)/18V | (100W+20W)/18V | (150W+30W)/18V | |||
Material | Mono crystalline silicon | |||||||
Solar cell efficiency | 19-20% | |||||||
Lithium battery | Capacity | 340WH | 420WH | 575WH | 650WH | |||
Charge cycle times | 2000 times | |||||||
Lamp head | Luminous flux | 4000-4500lm | 6000-6500lm | 7200-7500lm | 8400-9600lm | |||
Light output | 30W | 40W | 50W | 60W | ||||
LED qty | 105pcs | |||||||
LED chip | Bridgelux | |||||||
Color temperature | 3000-6000K | |||||||
CRI | ≥70Ra | |||||||
Material of lamp head | Aluminum alloy | |||||||
Elevation angle | 12° (attention to Dialux use) | |||||||
Lifespan | 50000hrs | |||||||
System | Light control voltage | 5V | ||||||
Light distribution | Batwing lens with polarized light | |||||||
Beam angle | X-axis: 140° Y-axis: 50° | |||||||
Lighting time(full charged) | 2-3 rainy days | |||||||
Operation temperature | -20℃~60℃ | |||||||
Installation | Top diameter of pole | 80mm | ||||||
Mounting height | 7-8m | 8-10m | ||||||
Installation spacing | 10-20m | 20-30m | ||||||
