Product Overview
Description
Product Description
Multilevel Rolling Bench
1. Make full use of the greenhouse height, expand the use of the greenhouse space.
2. Uniform each layer’s load with strong load capacity (90Kg/m2).
3. Easy management, convenient movement, and have a locking function and anti-turning device.
4. Easy to integrate with irrigation and drainage systems, lighting, airflow, and other equipment required for operation.
Multilevel rolling bench is mainly composed of C-shaped track (304#) square stainless-steel base, drive shaft control arm (304#), heavy-duty H bearing wheel, and driving shaft (304#), and heavy-duty special frame, etc.
Application: commercial indoor agricultural projects for nursery, flowers and vegetable cultivation, etc.
1. Make full use of the greenhouse height, expand the use of the greenhouse space.
2. Uniform each layer’s load with strong load capacity (90Kg/m2).
3. Easy management, convenient movement, and have a locking function and anti-turning device.
4. Easy to integrate with irrigation and drainage systems, lighting, airflow, and other equipment required for operation.
Multilevel rolling bench is mainly composed of C-shaped track (304#) square stainless-steel base, drive shaft control arm (304#), heavy-duty H bearing wheel, and driving shaft (304#), and heavy-duty special frame, etc.
Application: commercial indoor agricultural projects for nursery, flowers and vegetable cultivation, etc.
Tray Material | ABS |
Width | 1.2m,it can be Customized |
Length | 2.4/4.8/7.3/9.7m ,it can be Customized |
Tray thickness | 3.0mm(0.12’’) |
Tray depth | 70mm(2.76’’) |
Load bearing | 70-90kg |
UV protective ability | Yes |
Frame material | Aluminum alloy |
Fittings | Valve sump |
Composition | End trays, middle tray and division trays |
Color | Gray |
Work Principle
The nutrient solution is pumped from a reservoir underneath the growing tables until the water gets to a desired level. Then the nutrients slowly drain back down into a nutrient reservoir. When plants are flooded from below the water pushes oxygen-poor air out of the top of the bucket.
Details Images
ABS Tray
1. Food grade ABS raw material
2. UV resistant and eco-friendly
1. Food grade ABS raw material
2. UV resistant and eco-friendly
Anti-corrosion,anti-rust,durable than traditional iron mesh seed bed.
The tray can slide smoothly on the seed bed to improve production eficiency.
Easy and convenient installation, reduce labor cost.
Product packaging
Company Profile
Zhengzhou Huifa Machinery equipment Co., Ltd. is specialized in agricultural equipment design, research and development, production, installation, sales in one of the manufacturing enterprises. The main products are: single arch greenhouse, multi arch greenhouse, PC board greenhouse, avoid light greenhouse, tidal seedbed, logistics seedbed and so on. According to the requirements of customers in different regions, we tailor products of different categories and functions for customers.Products are exported to the United States, Thailand, Malaysia, Myanmar, North America, Canada, Australia and other countries.
FAQ
Q:1. Are you factory?
Yes,we are manufacturer for types of greenhouse for 10 years. With professional engineer team for suitable greenhouse
design,complete after-sale service and fac tory direct sale for you now!
design,complete after-sale service and fac tory direct sale for you now!
Q:2. How to ensure the quality of the products?
a. We have been focused on exporting for 10 years, goods had been exported to more than 20 countries and got good reputation in worldwide market. Long-term and mutual-benefits cooperation is our management philosophy.
b.To confirm every batch goods is in good condition,our inspection department will examine and test the products thoroughly and carefully before delivery. Neces- sary test and certification can be obtained as your request.
Q:3. Is there any instruction or manual guide installation?
a. Yes, English manual with drawing will be shipped to-gether with goods for guiding your installation easily.
b. Engineer overseas guiding installation is available.
c. Your worker or engineeris welcomed to our factory fo learning your greenhouse installation.
