Allen Bradley 1746 NIO4V Used Tested Cleaned Programmable Controller Cheap PLCs Controller
- Category: >>>
- Supplier: Radwell International llc
Share on (10000004668971):
Product Overview
Description
Product Description
ALLEN BRADLEY 1746-NIO4V (USED TESTED CLEANED)
1746NIO4V
DISCONTINUED BY MANUFACTURER 5/31/2021
I/O MODULE
VOLTAGE COMBINATION MODULE
SLC 500
HIGH RESOLUTION
ANALOG
2INPUT
2 OUTPUT
24 VDC
115 MA
I/O MODULE
VOLTAGE COMBINATION MODULE
SLC 500
HIGH RESOLUTION
ANALOG
2INPUT
2 OUTPUT
24 VDC
115 MA
Description
DISCONTINUED BY MANUFACTURER 5/31/2021; I/O MODULE; VOLTAGE COMBINATION MODULE; SLC 500; HIGH RESOLUTION; ANALOG; 2INPUT; 2 OUTPUT; 24 VDC; 115 MA - USED TESTED CLEANED - 2 YEAR RADWELL WARRANTY
Specification
Place of Origin | Willingboro, NJ |
Brand Name | ALLEN BRADLEY |
Model Number | 1746-NIO4V |
Input Channels per Module: | 2 Differential, Voltage or Current Selectable per Channel, Not Individually Isolated |
Outputs Channels per Module: | 2 Voltage Outputs, Not Individually Isolated |
Backplane Current Draw, 5 Volts: | 55 Milliamperes |
Backplane Current Draw, 24 Volts: | 115 Milliamperes |
Converter Resolution: | 16 Bits |
Repeatability: | ±1 LSB |
Non-Linearity: | 0.01% |
Channel Bandwidth: | 10 Hertz |
Step Response: | 60 Milliseconds at 95% |
Conversion Method: | Delta-Sigma Modulation |
Impedance Channel-to-Channel: | 1M Ohms |
Common Mode Rejection, 0 to 10 Hertz: | 50 Decibels |
Common Mode Rejection, 60 Hertz: | 105 Decibels |
Operating Temperature: | 0 to 60 degrees Celsius |
Storage Temperature: | -40 to 85 degrees Celsius |
Relative Humidity: | 5% to 95% (Non-Condensing) |
Operational Temperature: | 0 to 60 degrees Celsius |
Storage Temperature: | -40 to 85 degrees Celsius |
Relative Humidity (Operating): | 5% to 95% (non-condensing) |
Relative Humidity (Non-Operating): | 5% to 80% |
