10 cm wide 3k carbon fiber tape

Product Overview

Description

We are from taiwan and we can supply

carbon fiber  tape
fiber yarn can be 3k,6k,12k.
plain ,twill,satin
width can be 1inch ~15"
roll lentgh is  50m or 100m



The application is for composite parts application..

We can accept customers specification and produce in competitive price.



Best Regards





Oliver Chou

JINSOR Set weave finish carbon fiber fabrics specifications
Advantages: Set weave finish can fix the carbon fiber yarn and will not disorder the fabric even pulled by hands.

Code No (pictures&Application) weave pattern Thickness (mm) width(cm) weight(g/m2) counts/inch fiber photos warp weft warp weft JSC 0151P & Application Set weave Plain 0.16 50~200 136 17 17 1.5K 1.5K JSC 0151T & Application Set weave Twill 0.16 50~200 136 17 17 1.5K 1.5K JSC 0152P & Application Set weave Plain 0.17 50~200 162 20 20 1.5K 1.5K JSC 0153P & Application Set weave Plain 0.15 50~200 100 12.5 12.5 1.5K 1.5K JSC 0154P & Application Set weave Plain 0.16 50~200 145 18 18 1.5K 1.5K JSC 0156P & Application Set weave Plain 0.14 50~200 96 12 12 1.5K 1.5K JSC 0301P & Application Set weave Plain 0.3 50~200 200 12.5 12.5 3K 3K JSC 0302P & Application Set weave Plain 0.35 50~200 225 15 13 3K 3K JSC 0303P & Application Set weave Plain 0.35 50~200 240 15 15 3K 3K JSC 0304P & Application Set weave Plain 0.25 50~200 160 10 10 3K 3K JSC 0305P & Application Set weave Plain 0.25 50~200 164 12.5 8 3K 3K JSC 0306P & Application Set weave Plain 0.28 50~200 273 17 17 3K 3K JSC 0311T & Application Set weave Twill 2x2 0.3 50~200 200 12.5 12.5 3K 3K JSC 0312T & Application Set weave Twill 1x3 0.3 50~200 200 12.5 12.5 3K 3K JSC 0313T & Application Set weave Twill 2x2 0.35 50~200 240 15 15 3K 3K JSC 0313T3 & Application Set weave Twill 3x3 0.35 50~200 240 15 15 3K 3K JSC 0314T & Application Set weave Twill 2x2 0.25 50~200 160 10 10 3K 3K JSC 0316T4 & Application Set weave Twill 4x4 0.38 50~200 272 17 17 3K 3K JSC 0321S & Application Set weave Satin 8H 0.42 50~200 368 23 23 3K 3K JSC 0322S & Application Set weave Satin 5H 0.4 50~200 280 17.8 17.8 3K 3K JSC 0601P & Application Set weave Plain 0.5 50~200 320 10 10 6K 6K JSC 0604P & Application Set weave Plain 0.4 50~200 290 9 9 6K 6K JSC 0611T & Application Set weave Twill 2x2 0.5 50~200 320 10 10 6K 6K JSC 0612T & Application Set weave Twill 2x2 0.55 50~200 400 12.5 12.5 6K 6K JSC 0613T & Application Set weave Twill 2x2 0.35 50~200 205 6 7 6K 6K JSC 0621S & Application Set weave Satin 5H 0.55 50~200 380 12 12 6K 6K JSC 1201P & Application Set weave Plain 0.65 50~200 510 8 8 12K 12K JSC 1202P & Application Set weave Plain 0.65 50~200 576 8 10 12K 12K JSC 1204P & Application Set weave Plain 0.6 50~200 378 6 6 12K 12K JSC 1211T & Application Set weave Twill 2x2 0.65 50~200 510 8 8 12K 12K JSC 1212T & Application Set weave Twill 2x2 0.65 50~200 576 8 10 12K 12K JSC 1213T & Application Set weave Twill 2x2 0.7 50~200 650 10.5 10.5 12K 12K JSC 1214T & Application Set weave Twill 2x2 0.6 50~200 378 6 6 12K 12K JSC 1215T & Application Set weave Twill 2x2 0.6 50~200 630 10 10 12K 12K JSC 2401P & Application Set weave Plain 0.85 50~200 770 5 7 24K 24K SCP100 & Application Set weave Plain 0.13 100 100 1.6 1.6 16mm spread 12K 16mm spread 12K Carbon fiber fabrics application are as follows 1. carbon sporting goods: golf shaft,tennis racket,ski board,snow board,surfboard,fishing rod... 2. carbon car parts: hood,front fender,steering wheel,gear shift,mirror cover,trunk cover. 3. carbon shoes parts:shoes sole,shoes trim... 4. carbon boat parts:mast,kayak,loom,loom blade,boat shell. 5. carbon electronic parts:speaker cone,mobile phone shell,carbon laptope shell.
