Model | VLTB | ||||
Horsepower | 85 | 95 | 110 | 120 | 150 |
Wheel Drive | 4×4 (4×2) | ||||
Dimension(L*W*H)mm | 4530×2050×2930(4530×1980×2630) | ||||
Weight(kg) | 3690~3840 | ||||
Front wheel Tread(mm) | 1490,1580,1650,1740 adjustable | ||||
Rear Wheel(mm) | 1520,1620,1740,1850 adjustable | ||||
Wheel Base(mm) | 2195(1970) | ||||
Min Land Clearance(mm) | 405(390) | ||||
Gear shifts | 16F+8R | ||||
Tyre Size | 16.9-34/12.4-24(14.9-30/8.3-20) | ||||
Engine Specification | |||||
Brand | QC / YTO / WEICHAI | ||||
Type | water cooled ,Vertical,4 stroke and Direct injection | ||||
Rated Power(KW) | 62.5 | 69.9 | 80.9 | 88.2 | 110.3 |
Rated Revolution(r/min) | 2300/2400 | ||||
Start Way | Electricity Start | ||||
Transmission | 4×(2+1)×2 shift | ||||
Clutch | Dry friction and double stage clutch,separate operation | ||||
PTO Speed | 6 spline 540/760 or 760/850 | ||||
