Shock & Acceleration Detecting Switch RBS02 series shock switch
- Category: Other Switches >>>
- Supplier: ONCQUE CORPORATION
Share on (10000007071196):
Product Overview
Description
Product Description
RBS02 series
Horizontal Tilt detecting / Vertical Rotation detecting / Shock detecting
● Suitable for Horizontal PCB.
● Tiny size, suitable for small space.
● Wing-shaped terminals, a feature enables half body of the sensor switch to be buried into PCB.
● Gold-plated ball and terminals, low possibility of oxidization.
● All plastic materials subject to industrial purpose, resist high temperature and meet fireproof function.
● Simple ON and OFF signals, easy for design.
● RoHS compliance, an ideal substitute for mercury switch.
● A more economical tilt and rotation detection option than IC design solution.
● All made in TAIWAN and EXAMINED before shipment.Tilt / Rotation detection
Uncertain degree: θ< 20°
Switch state: Normal Open (SMD)
Conductive Rate: 85% min.
Tilt / Rotation detection
Uncertain degree: θ< 10°
Switch state: Normal Open (SMD)
Conductive Rate: 90% min.
Tilt / Rotation / Shock detection
Triggered Angle Range:θ>20°,θ<-20°
Switch state: Normal Open (SMD)
Conductive Rate: 80% min
Vibration / Shock detection
Acts like a Normally Closed switch which chatters open and closed as it is tilted or vibrated.
Conductive Rate: 90% min.
Model | RBS020602 | RBS020902 | RBS021002 | RBS021102 |
Operating Angle | θ <20° | θ <20° | -- | θ <10° |
Switch state | SMD Normal Open | SMD Normal Open | SMD | SMD Normal Open |
Dimension(mm) | Φ4*13.6 | Φ3*7.8 | Φ3*8.4 | Φ4*9.6 |
PCB direction | Horizontal PCB | Horizontal PCB | Horizontal PCB | Horizontal PCB |
IR Reflow | Manual Soldering Suggest | Peak temp.=255~260°C | Manual Soldering Suggest | Peak temp.=255~260°C |
Note
For the continued product improvement as one of the company policy, specifications may change or update without notice. The latest information can be obtained through our sales offices. Normally, all products are supplied under our standard conditions.
