ZCS160 4 In 1Magstrip card reader, RFID/PSAM Card Reader Writer With Certification

Introduction
ZCS160 is a muti-functional card reader.It can read magnetic Stripe card, read and write IC chip card,RFID Card and PSAM card. Through the USB interface can connection with related equipment .
It is widely used in industry and commerce, telecommunications, taxation, banking, insurance, health care and a variety of charges, stored value, query management system.

Feature
Interface：USB（RS232,Bluetooth optional)，play and plug ,Support magnetic card data output by analog keyboard ,support IC card & PCSC standard interface .

Compatibility：compatible ISO7811、AAMVA、CADMV magnetic card standard，support ISO7816，Support all types of memory encryption cards AT24C01A/24C02/24C04/24C08/24C16/AT24C64,SLE4432/4442,SLE4418/4428，EMV IC card standard，Support ISO14443 TYPA A&B Mifare One S50,Mifare One S70,MifareOne Mini,Mifare Ultra Light,Desfire,Mifare Plus

Technical Advantage：Provide complete dynamic library functions ,support WINDOWS/LINUX/Android system，provide convenient DLL secondary development.Provide complete dynamic library functions, development, main points, call example source code examples, and various development language(including: vb6.0 ,java ,vc++6.0，Android，LINUX development)

Technical Specification

Electric
electric source ：USB interface
Current：45~65 mA
Communications
Interface：USB2.0、USB-OTG（Android3.1 above）,RS232 Bluetooth(optional)
material: ABS
Device Dimension: 160mm(L) ×45mm(W) × 45mm(H)
Device Weight: 180g
Package Dimension : 204mm(L) ×84mm(W) × 60mm(H)
Package Weight: 252g
Color: Black

Magnetic
Reader：1/2/3 tracks optional
Swipe：double direction
Head life：about 500,000 passes
Parity and LRC checking：Built-in, audible and LED good read and error indicator
Cards support：ISO 7811,AMMVA,CADMV
Environment Working temperature：0℃ ~ 55 ℃
Working Humidity：10%~90% relative humidity
Storage Temperature：-30℃~70℃
Storage Humidity：10%~90% relative humidity RFID Card
Operating Frequency：13.56 MHz
Smart Card Interface：ISO14443-A, Mifare 1
Sensing Distance：0-5cm
Buzzer：Programmable control buzzer on / off
Cards Support:
ISO14443A,MifareOneS50,MifareOneS70,MF3
DESFIRE, Ultralight、ISO14443B 、SONY felica

Shenzhen ZCS Technology Co., Ltd. is a global leader in electronic devices and secure electronic pos technologies. We provide 3G/4G Smart POS,Magstripe,Smart card Reader/Writer, Mobile pos solutions, services. Leading with innovation and engineering excellence,our products are provided through OEMs, VARs, distributors, and directly to major end users. Our products are feature rich and provide practical, economical solutions to our customers needs.

In order to meet the needs of our customers, we focus on a strategy of continuous customer-centric innovation. The goal of our product R&D is to deliver timely solutions for anticipated and actual customer needs by developing innovations in technologies, products, solutions and services.With a strong hardware and software engineering team, ZCS technology is able to quickly and cost-effectively develop any application required globally.Our innovations are central to important cutting-edge technologies, including the mobile payment which allows merchants and mobile workforces to process through their mobile phones.

We strive to improve our products and services.We also welcome any OEM/ODM business, welcome to any better suggesstions or comments. We offer most of our products with 2-year warranty and free technical support. Your choice is our glory and pride. "No Best, Only Better" is our promise. Thanks for choosing us.

1. who are we?
We are based in Guangzhou, China, start from 2009,sell to Africa(27.50%),Western Europe(17.50%),Eastern Europe(12.50%),Domestic Market(10.40%),South Asia(10.30%),Mid East(9.80%),Southeast Asia(5.00%),North America(1.00%),Southern Europe(1.00%),Northern Europe(1.00%),Oceania(1.00%),Central America(1.00%),South America(1.00%),Eastern Asia(1.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
POS,Card Reader,Bluetooth Printer,Tablet

4. why should you buy from us not from other suppliers?
10-year professional payment solution provider and manufacturer
Factory-- located in Bao'an, Shenzhen,China
Certificate--ISO 9001 CE FCC RoHS
SDK/API for the products
Strong presence in ODM project
