Stainless Steel Double Bucket Portable Cow Milking Machine

Product Overview

Description

1. Introduction of the portable goat milking machine/ vacuum milking machine:

The portable goat milking machine/ vacuum milking machine is composed of the milker and vacuum unit which is widely used in the animal husbandry, daily products processing industry for cow, cattle, goat, sheep etc.

It is adopting the pumping action which is produced by the vacuum unit, imitating the sucking action of the animals, then sucking the milk out.



2. Structure of the portable goat milking machine/ vacuum milking machine:

One set of the portable goat milking machine/ vacuum milking machine is constituted by pulsator, cluster, vacuum pump, electric motor, stainless steel milking cups, rubber milking liners and milk tube, air tube, stainless steel milk bucket etc. Vacuum system is constituted by light vacuum pump (blade), auto-stop vacuum valve, muffler, vacuum pot, vacuum manostat, vacuum ball-valve, vacuum watch, etc.

3.Model and parameter:

Piston moving single bottle cow milking machine

Model:NCHT-I

Motor power:550W

Material of container: Stainless steel

Volume of container:25 liter

Single bottles: 10-15 cows/hour

Size:0.95*0.35*0.9m

Include 4 nipples

Piston moving double bottle cow milking machine

Model:NCHT-2

Size:0.95*0.9*0.8m

Capacity:18-22cows/h

Size:0.95*0.8*0.9m

Motor:1.1kw

Material of container: Stainless steel

Volume of container:25 liter

Include 8 nipples



Vacuum Moving single bottle cow milking machine

Model:NCHT-3

Motor power: 0.75kw

Single bottles: 10-15 cows/hour

Material: Stainless steel

Volume of container:25 liter

Size:0.95*0.35*0.9m

Include 4 nipples



Vacuum Moving double bottle Cow Milking machine

Model:NCHT-4

Motor power: 1.5kw

Double bottles: 20-24 cows/hour

Material: Stainless steel

Motor power: 0.9-1.1kw
Volume of container:30 liter

Size:0.95*0.8*0.9m

Include 8 nipples
