99.95% pure tungsten electrode welding new tungsten electrodes tig welding easy to tungsten electrode welding rod
- Category: >>>
- Supplier: Yolo Materials Industry Co. Ltd.
Share on (10000008880946):
Product Overview
Description
PRODUCT SPECIFICATIONS
Item | Data |
Product name | Grey 2% Ceriated 0.04" x 3.5" Pre-Ground TIG Tungsten Sharpened Electrodes |
Color | Grey |
Application | Welding |
Instrument type | Tig welding consumables |
Wire Diameter | 0.04" or 1.0mm |
Ball Diameter | 3.5" or 89mm |
Taper degree | 12, 23, 30 or request |
Materials | 2% Ceriated Tungsten |
Package | Strong plastic boxes |
Grinding Services
Yolo provides any degree of the pre-ground welding tips with single end or 2 ends, which saving your lot of time.
* Flat head
* Pointed head
Grinding Direction
Axial Grinding Direction
Yolo provide axial pre-ground tungsten electrode instead of lateral one. Since axial grinding not only enables deeper penetration, but also helps the welder easily controls the energy applied.
The lateral one will lead to a wider arc cone, which results in weak penetration.
Product Paramenters
Whether you want pre-ground tungsten electrodes in regular size or custom size, Yolo is able to produce large quantities
With Yolo’s state-of-the-art drawing and sharpening equipment, especially for ultra-fine electrodes of 1/4″ diameter, Yolo is able to accurately guarantee the accuracy of the taper and surface finish.
Pre-Ground Electrode Diameter | Pre-Ground Electrode Length | Pre-Ground Electrode Angle |
Customized are available | Customized are available | Customized are available |
0.04" | 1.375" | 15 degree |
1/16" | 1.5" | 20 degree |
3/32“ | 2.25" | 25 degree |
1/8“ | 2.6" | 30 degree |
5/32“ | 3" | |
3.5" |
Materials Choice
Type | Mark | Price |
Blue 2% Lanthanated Pre-Ground TIG Tungsten Sharpened Electrodes | WLa20 | Get price now |
Grey 2% Ceriated Pre-Ground TIG Tungsten Sharpened Electrodes | WCe20 | Get price now |
Yellow 1.5% Lanthanated Pre-Ground TIG Tungsten Sharpened Electrodes | WLa15 | Get price now |
Red 2% Thoriated Pre-Ground TIG Tungsten Sharpened Electrodes | WTh20 | Get price now |
White 0.8% Zirconium Pre-Ground TIG Tungsten Sharpened Electrodes | WZr8 | Get price now |
Purple Pure Tungsten Pre-Ground TIG Tungsten Sharpened Electrodes | WP | Get price now |
Product packaging
Why Choose Us
manufacturers of tungsten powder raw materials . The overall particle uniformity of APT raw materials we use is better than that of other companies in the market, which can guarantee the overall quality.
Yolo: Uniform particle size
Title goes here.
Flaw Detection
Yolo will have corresponding inspection for each process. 100% flaw detection to the 0.39mm thick wire end to confirm the crack.
Under flaw detection, there are Grade A (eg: 2 crack points per 100 meters), B, C Grade. Any level wire below C will be removed, since the more cracks, the more easily the yarn are broken during processing.
Under flaw detection, there are Grade A (eg: 2 crack points per 100 meters), B, C Grade. Any level wire below C will be removed, since the more cracks, the more easily the yarn are broken during processing.
