France Popular Golf Carts With CE Certification High Quality Golf Cart Can Be Customized Cheap Price

Share on (10000009077507):


Price:$800.00 - $900.00

Quantity:


Product Overview

Description


72v golf cart with lithium battery 6 person lifted golf cart electric golf cart 6 seater




Product Application





LS2020ASZ is a 4 Seat Electric Off Road Golf Car Dune Utility Vehicle Buggy with rear facing flip flop seat, it's powered by lithium battery and 72V/5KW AC motor. The rear flip flop seat can be either used for people moving or cargo delivery.  The big teeth off road tire makes it to be suitable for using many places for different applications, such as in hotel, resort, residential community, airport, port, stations, museum, theme park, factory, campus, garden and any places where need a quite and clean vehicles, etc..


















































































































































SPECIFICATIONS OF 4 Seat Electric Off Road Golf Car Dune Utility Vehicle Buggy LS2020ASZ






Key Components



Controller


Toyota Brand


Motor


5KW AC motor


Battery


72V120AH Lithium Battery











Performance

and

Dimensions



Passenger Capacity


4 (2+2)


Range (Loaded) *


70-80kms


Max.speed


32-40km/h


Min. Turning Radius


3m


Max. Gradeability


20%


Max. Loading Weight


320kgs


Net Weight


510kgs


Overall Dimensions


2950X1340X1990mm



Body and Frame



Frame (Chassis)


Welded steel framework, with anti-rust treatment of acid washing, phosphating and electro-coating


Body and Roof


PP plastic front body and rear body; FRP roof


Windshield


Organic plastic windshield, one-piece


Roof supports


Carbon Steel, powder coated


Backrest and Seat


Reborn Sponge, artificial leather + plastic armrest


Floor


Galvanized Steel plate and anti-slip rubber floor mat


Dashboard


Plastic in black, with 4 cup holders, 2 glove storage box, forward/reverse switch, battery capacity indicator, ignition key


Side trim


Aluminum alloy


Sider mirror


2pcs, foldable


Electric System


Lighting system and horn


All LED lights, 2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with 20A voltage reducer (converting from 72V to 12V), electric horn.


Backup Buzzer


12V


Charger


Smart charger, input 110V-240V~50Hz-60Hz, output 72V, 20A


Steering, Brake, Transmission and Suspension


Steering System


Single-stage rack and pinion steering system, automatic rocker compensating function


Brake system


Rear wheel mechanical brake, foot activated parking brake


Accelerator


Stepless speed change


Driving mode


Rear axle two stage deceleration, motor direct driving


Rear axle


Integrated, Gear ratio12.49:1


Suspension system


Front and rear plate leaf spring + cylinder hydraulic shock absorber


Wheel & Tyre


10x8 aluminum rim & 22*11-10 Tire














FAQ

FAQ







Q1. Do you accept to customize the vehicles as per our special request?


Answer: Yes, we customize vehicles as per customer's speical request with reasonable cost and lead time, as long as the customization is not related to the chassis modification.

Q2. What is your warranty term?

Answer: We provide 1 year warranty. And for any failed part under warranty, if it can be repaired at your side and the repair cost is lower than the valve of the part, we will cover the repair cost; otherwise, we will send replacements and cover the freight cost if any.

Q3. Do you provide after service spare parts?

Answer: Yes, we provide all the spare parts to our vehicles, even 5 years after we stop the production of the vehicle. For your easier working to select the spare parts, we also supply parts manual.

Q4. Do you provide technical support?

Answer: Yes, we provide technical support by email and phone. If necessary, we can also send our engineer to your place.

Q5. Do you provide vehicle assembly service if we buy the vehicles in SKD or CKD way?

Answer: When the vehicle is in SKD way, the reassembly is just bolt and nut work, it is not difficult at all. Unless you have the assembly capability, we do not sell the vehicles in CKD way. If you do have bigger volume, we can send our people to give instructions.

Q6. Do you accept OEM order?

Answer: Yes, as long as the order quantity is reasonable (yearly 300-500 units), we will accept.

Q7. What are your terms to be your agent/dealer in my country?

Answer: We have several basic requirements, firstly you shall be in electric vehicle business for some time; secondly, you shall have the capability to provide after service to your customers; thirdly, you shall have the capability to order and sell reasonable volume of electric vehicles.

Q8: What is your payment term?

Answer: For new customers, our typical payment term is ‘T/T 30% deposit against order confirmation, T/T 70% before container loading’. Irrecoverable L/C at sight is also acceptable. For old customers, our payment term can be more flexiable. Please contact us for more information
