MF 385 2WD PERFORMANCE: |
|
Max. Engine power @ 2,200 rpm
Max. Torque @ 1,400 rpm
Max. PTO power @ Rated
Engine rpm
*Certified to BS AU 141a
** Manufacture’s estimate
|
85 hp*
291 Nm
70 hp**
|
|
|
MF 385 2WD ENGINE:
Make/Type
No. of Cylinders
Injection
Bore
Stroke
Capacity
Aspiration
Compression Ratio
Starting Aid
Throttle Control
Cooling
Air Cleaner Type
Air Pre-Cleaner
Fuel Filter
Exhaust
Oil Cooler
|
Perkins / 4.41
4
Direct
101 mm
127 mm
4.1
Natural
15.3:1
Thermostart
Hand and Foot
Water
Oil Bath
Over Bonnet, Air Swirl
Dual High Capacity
Vertical; Muffler
Under Bonnet
Water Cooled
|
|
|
MF 385 2WD ELECTRICS: |
|
Voltage
Battery
Starter
Alternator |
12V, Negative Earth
96 Ah
2.8 KW
45 Amp. |
|
|
MF 385 2WD CLUTCH: |
|
Type
Diameter
Lining Material |
Dual
305x254 mm
Cerametallic |
|
|
MF 385 2WD POWER TAKE - OFF: |
Type
Engine Speed @ 540 PTO rpm
Shaft Diameter
No. of Splines |
Live
1,789 rpm
35 mm
6 |
|
|
MF 385 2WD TYRES: |
|
Front 7.50-16 (6PR)
Rear 18.4 / 15-30 (6PR) |
7.50-16 (6PR)
18.4 / 15-30 (6PR) |
|
|
MF 385 2WD TRACK ADJUSTMENT: |
Front Axle
Rear Axle |
1,271 - 1,881 mm
1,423 - 2,134 mm |
|
|
MF 385 2WD STEERING: |
|
Type |
Hydrostatic |
|
|
MF 385 2WD TRANSMISSION: |
Type
Number of Gears |
Sliding spur
8 Forward, 2 Reverse |
Road speed @ 2,200 Engine rpm with
18.4/15-30 Rear Tyres |
Gear Speed
Forward 1
Forward 2
Forward 3
Forward 4
Forward 5
Forward 6
Forward 7
Forward 8
Reverse 1
Reverse 2 |
(km/hr)
2.7
3.7
5.1
6.8
10.4
15.2
20.8
27.9
3.5
14.1 |
|
|
MF 385 2WD HYDRAULICS: |
|
Function
Pump Type
Maximum Oil Flow
Maximum pressure
Maximum Lift Capacity
with Lower Links
Horizontal
Lower links
|
Draft Control, Position
Control, Response Control,
Constant Pumping
4 Piston, Ferguson Pump
16.7 liters / min
21 MPa at normal operating
temperature
2,145 kg
Category I & II with
Interchangeable balls
|
|
MF 385 2WD FRONT AXLE: |
Axle Type
Brake Type
Brake Pedal
Braking Area
Brakes Actuation
Parking Brake
|
Straddle with
epicyclic reduction unit
Oil Immersed, Multi-Disc
Pendant
1774 sq.cm
Hydraulic
Hand Lever Operated |
|
|
MF 385 2WD REAR AXLE & BRAKES: |
Axle Type
Brake Type
Brakes Area
Brakes Actuation
Parking Brakes
|
Straddle with epicyclic
Reduction
Oil immersed, multi - disc
1,774 Sq. cm.
Hydraulic
Hand Lever Operated |
|
|
MF 385 2WD CAPACITIES: |
Fuel Tank
Engine Sump
Cooling System
Hydraulic System
Hydrostatic Steering
Reservoir
Oil Bath Air Cleaner |
108.0 lit
7.5 lit
15.2 lit
36.0 lit
2 lit
0.7 lit
|
|
|
MF 385 2WD INSTRUMENTATION: |
Gauges
Warming Lights
|
Tachometer, Hourmeter,
Fuel Level, Battery Condition &
Water Temperature
Direction Indicators
Electric Charge,
Headlight Main Beam,
Low Engine Oil Pressure,
Brake Lights
|
|
|
MF 385 2WD WEIGHT & DIMENSIONS: |
with 7.50-16 Front & 18.4/15-30 Rear Wheel
and with full Fuel, Oil & Water |
Weight
Gross Weight
Dimensions
Wheel Base
Overall Length
Width (minimum)
Height
Over Exhaust
Over Steering Wheel
Turning Circle
Without Brakes
Ground Clearance
Under Gearbox
|
2,440 kg
2,286 mm
3,760 mm
1,871 mm
2,485 mm
1,781 mm
7,502 mm
501 mm
|
|
|
MF 385 2WD STANDARD EQUIPMENT: |
Weight Frame without Weights
Standard Tool Box with Set of Tools
Top Link
Top Link End
Cat-I & II Balls
Check Chains
Chain Stablisers
Spring Suspension Seat
Flat Top Fenders &
Operator’s Manual |
|
|
MF 385 2WD OPTIONAL EQUIPMENT / ACCESSORIES: |
Cabin (A/C or Non-A/C)
Sun Canopy (ROPS Style)
Front Ballast/Weights
Adjustible Pintle Hook, Simple Pintle Hook
Swinging Drawbar, 9 Hole Drawbar
Auto Hitch
Hydraulic Control Outlets/Spool Valves
External Electric Switch
PTO Belt Pulley &
International Warranty Tool Kit |
|
