THREAD REPAIRING INSERT INSTALLATION TOOLS T TYPE

Product Overview

Description

Insertion Tools with break-Off tang



with Adjustment Bush,  Square Drive,  Allen Screw and  with Vinyl Grip



Powder Coated Finish



Material – Alloy Steel



Size – M2 To M33



For Wire Thread Inserts – 1.0D, 1.5D, 2.0D, 2.5D, 3.0D MM







Item Code No.   Insertion Tool



T Type   UNC / UNF          BSW / BSF           Insertion Tool     Break off



Tang       Square Drive



mm



ABM-TRK-5700 M5 x 0.8              UNC/UNF No. 12              BSF 3/16              No. 8     No. 8     6.0



ABM-TRK-5701 M6 x 1.0              UNC/UNF No. 1/4            BSW/BSF 1/4     No. 9     No. 9     6.3



ABM-TRK-5702 M7 x 1.0              UNC 5/16            BSW 5/16            No. 10   No. 10   6.3



ABM-TRK-5703 M8 x 1.25            UNF 5/16            BSF 5/16              No. 11   No. 11   6.3



ABM-TRK-5704 M8 x 1.0              xx            xx            No. 11   No. 11   6.3



ABM-TRK-5705 M9 x 1.25            UNC 3/8               BSW 3/8              No. 12   No. 12   6.3



ABM-TRK-5706 M10 x 1.5            UNF 3/8               BSF 3/8 No. 13   No. 13   8.0



ABM-TRK-5707 M10 x 1.25         UNF 3/8               BSF 3/8 No. 13   No. 13   8.0



ABM-TRK-5708 M10 x 1.0            xx            xx            No. 13   No. 13   8.0



ABM-TRK-5709 M11 x 1.5            UNC/UNF 7/16 xx            No. 14   No. 14   8.0



ABM-TRK-5710 M11 x 1.25         xx            BSW/BSF 7/16   No. 14   No. 14   8.0



ABM-TRK-5711 M12 x 1.75         UNC/UNF 1/2    xx            No. 15   No. 15   9.0



ABM-TRK-5712 M12 x 1.5            UNC/UNF 1/2    xx            No. 15   No. 15   9.0



ABM-TRK-5713 M12 x 1.25         xx            BSW/BSF 1/2     No. 15   No. 15   9.0



ABM-TRK-5714 M12 x 1.0            xx            BSW/BSF 1/2     No. 15   No. 15   9.0



ABM-TRK-5715 M14 x 1.5            UNC/UNF 9/16 xx            No. 16   No. 16   9.0



ABM-TRK-5716 M14 x 2.0            xx            BSW/BSF 9/16   No. 16   No. 16   10.0



ABM-TRK-5717 M14 x 1.25         xx            xx            No. 17   No. 16   10.0



ABM-TRK-5718 M14 x 1.0            xx            xx            No. 17   No. 16   10.0



ABM-TRK-5719 M16 x 2.0            UNC/UNF 5/8    xx            No. 18   xx            xx



ABM-TRK-5720 M16 x 1.5            xx            BSW/BSF 5/8     No. 18   xx            xx



ABM-TRK-5721 M18 x 2.5            UNC 3/4               xx            No. 20   xx            xx



ABM-TRK-5722 M18 x 2.0            xx            BSW/BSF 3/4     No. 20   xx            xx



ABM-TRK-5723 M18 x 1.5            UNC 3/4               xx            No. 20   xx            xx



ABM-TRK-5724 M20 x 2.5            UNF 3/4               xx            No. 21   xx            xx



ABM-TRK-5725 M20 x 2.0            xx            xx            No. 21   xx            xx



ABM-TRK-5726 M20 x 1.5            UNC 3/4               xx            No. 21   xx            xx



ABM-TRK-5727 M22 x 2.5            UNC/UNF 7/8    xx            No. 22   xx            xx



ABM-TRK-5728 M22 x 2.0            xx            BSW/BSF 7/8     No. 22   xx            xx



ABM-TRK-5729 M22 x 1.5            UNC/UNF 7/8    xx            No. 22   xx            xx



ABM-TRK-5730 M24 x 3.0            UNC/UNF 1        xx            No. 23   xx            xx



ABM-TRK-5731 M24 x 2.0            xx            BSW/BSF 1          No. 24   xx            xx



ABM-TRK-5732 M24 x 1.5            UNC/UNF 1        xx            No. 25   xx            xx



ABM-TRK-5733 M27 x 2.5            xx            xx            No. 26/27           xx            xx



ABM-TRK-5734 M33 x 3.0            xx            xx            No. 30/33           xx            xx
