CV 2000B Advanced Bipolar Electrocoagulation Machine/Electrosurgical Biopolar Forceps

Product Overview

Description

CV-2000B Advanced Bipolar Electrocoagulation Machine/Electrosurgical Biopolar Forceps



Main Features:

a)  Deep hemostasis, foot control outputs, mild hemostasis.
b) According to the depth of hemostasis, the output mode stops automatically. The output power will not reduce when operating in dry and bleeding spot.
c)Foot control mode: When the tissue reach the coagulation effects, the output power declines slowly.
d) Auto mode: when the tissue or blood vessel was coagulated, output power drops off sharply, to keep the forceps from sticking and over burnt for tissues.
e) Low voltage effectively reduces forming of the sparking of forceps, stimulating for the neuromuscular, to increase the security.
f)  Microcontroller system allows this unit can be used in many delicate surgery.
g)  Bipolar cut :macro bipolar.

Technical specifications For bipolar electrocoagulation machine :

1) Two working modes: bipolar coag,bipolar cut

2) Power: 220V±22V(110V±11V) 50Hz±1Hz

3) Working frequency:1024KHz

4)Output power:

  a) bipolar coag:1-120W(load 200Ω)

  b) bipolar cut:1-120W(load 200Ω)

Configuration For  Electrosurgical Unit

Footswitch                                                  1set

None sticky bipolar Forceps and cable           1set

Bipolar cut  pencil                                       1piece
