Chinese Plumbing Machinery Pipeline Equipment Tube Mill Production Line Manufacturers GXG Technology

Product Overview

Description



TUBE MATERIAL:Stainless Steel/Copper/Carbon Steel/Iron/Galvanized Etc

PIPE SHAPE:Round/Square/Rectangle/Special-shaped Etc

USDAGE:Pipes for Furniture, Construction, Municipal Facilities etc Fields



Chinese Plumbing Machinery Pipeline Equipment Tube Mill Production Line Manufacturers Stainless steel welding pipe making machine tube mill is a professional equipment which mainly produces decorative pipes. It can be used in the production of handrails, railings, tables and chairs, doors, windows and other pipes with low strength and high ornamental requirements. It can produce round, square, rectangular, special-shaped and other shapes. It is suitable for the manufacture of stainless steel, iron, copper/galvanized and other metal materials.

MODEL	Round Tube Range (mm)	Square Tube Range (mm)	Wall Thickness Range (mm)	Horizontal Shaft Diameter (mm)	Vertical Shaft Diameter (mm)	Main Motor Power (kw)	Installation Dimension (L*W  m)	Rated Voltage (v)
GXG-S40	Ø5—31.8        1/5”—1-1/4”	5*5—25*25	0.15—0.8  / 0.5	Ø40	Ø25	5.5	21*1	220   380   415     440
GXG-40	Ø9.5—50.8  3/8”—2”	8*8—40*40	0.23—1.5  / 1.2	Ø40	Ø25	7.5	22*1.2
GXG-L40	Ø15.9—63.5  5/8”—2-1/2”	13*13—50*50	0.30—1.8  / 1.3	Ø40	Ø25	7.5	23*1.2
GXG-50	Ø19.1—76.2 3/4”—3”	20*20—60*60	0.35—2.5  / 1.5	Ø50	Ø30	11	25*1.3
GXG-60	Ø31.8—114.0 1-1/4”—4-1/2”	30*30—90*90	0.55—3.0  / 2.0	Ø60	Ø35	15	28*1.5
