ANNKE 2MP ANPR IR 4X Varifocal Network Camera IP67 Waterproof AI Detection HD 1080P LPR POE IP Security Camera NEMA 4X
- Category: >>>
- Supplier: Shenzhen Kean Digital Co. Ltd.
Share on (10000014184802):
Product Overview
Description
Product Description
Specification
Image Sensor | 1/1.8” progressive scan CMOS |
Min. Illumination | Color: 0.0005 Lux @ (F1.2, AGC ON), B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR |
Shutter Speed | 1 s to 1/100,000 s |
Day & Night | IR cut filter, Blue glass module to reduce ghost phenomenon |
Day/Night Switch | Day, night, auto, scheduled-switch |
Focal Length & FOV | 2.8 to 12 mm, horizontal FOV 100.8° to 40.2°, vertical FOV 53.3° to 22.5°, diagnol FOV 122.3° to 46.2° |
Focus | Auto, semi-auto, manual |
Aperture | 2.8 to 12 mm: F1.38 to F2.5 |
DORI | Wide:2.8 to 12 mm: D: 60 m, O: 23.8 m, R: 12 m, I: 6 m Tele: 2.8 to 12 mm: D: 149 m, O: 59.1 m, R: 29.8 m, I: 14.9 m |
Supplement Light Type | IR |
Supplement Light Range | 2.8 to 12 mm: 60 m |
Smart Supplement Light | Yes |
IR Wavelength | 850 nm |
Main Stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720) |
Sub-Stream | 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
Third Stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
Fourth Stream | 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
Fifth Stream | 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264 Sub-stream/Fourth stream/Fifth stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
Video Bit Rate | 32 Kbps to 8 Mbps |
Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3 |
Audio Bit rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64Kbps (AAC-LC)/8 to 320 Kbps (MP3) |
User/Host | Up to 32 users. 3 levels: Administrator, Operator and User |
Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication(EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log,TLS 1.2 |
White Balance | Auto,ATW,sodium lamp,fluorescent lamp,indoor,outdoor,MWB,Locked WB |
Digital Zoom | 16 × |
Optical Zoom | 32 × |
General Function | Mirror, password protection, watermark, IP address filter |
Basic Event | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, abnormal reboot, HDD full, HDD error), video quality diagnosis, vibration detection |
Smart Event | Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)), Scene change detection, audio exception detection, defocus detection |
Linkage | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning |
Web Client Language | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian,Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish,Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese,Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
Protection | IP67 |
Anti-Corrosion | NEMA 4X |
