ANNKE C800 Bullet 8MP 4K Ultra HD PoE ONVIF PoE IP Security Camera with H.265+ Coding Outdoor Indoor IP67 Weatherproof Audio Recording Supports 256 GB TF Card Remote Access | ||
Image sensor | 1.3" Progressive Scan CMOS | |
Max. Resolution | 2688 × 1520 | |
Min. Illumination | Color: 0.005 Lux @ (F1.2, AGC ON),B/W: 0.001 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR | |
Shutter Time | 1 s to 1/100,000 s | |
Day & Night | IR cut filter | |
Angle Adjustment | Pan: -90° to 90°,tilt: 0 to 60° (2.8 mm),0 to 70° (4/6 mm),rotate: 0° to 355° | |
Focal Length & FOV | 2.8 mm, horizontal FOV 98.2°, vertical FOV 54.2°, diagonal FOV 114.6° 4 mm, horizontal FOV 78.8°, vertical FOV 40.5°, diagonal FOV 93.9° 6 mm, horizontal FOV 49.1°, vertical FOV 26.3°, diagonal FOV 57.2° | |
Lens Mount | M12 | |
Aperture | F1.6 | |
DORI | 2.8 mm: D: 61.1 m, O: 24.2 m, R: 12.2 m, I: 6.1 m 4 mm: D: 85.4 m, O: 33.9 m, R: 17.1 m, I: 8.5 m 6 mm: D: 128.0 m, O: 50.8 m, R: 25.6 m, I: 12.8 m | |
Supplement Light Type | IR | |
Supplement Light Range | Up to 10 m | |
Smart Supplement Light | Yes | |
IR Wavelength | 850 nm | |
Main Stream | 50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 24 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) | |
Sub-Stream | 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 24 fps (704 × 480, 640 × 480) | |
Third Stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 24 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) | |
Video Compression | Main stream: H.265/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264 | |
Video Bit Rate | 32 Kbps to 8 Mbps | |
H.264 Type | Baseline Profile,Main Profile,High Profile | |
H.265 Type | Main Profile | |
Bit Rate Control | CBR/VBR | |
Scalable Video Coding (SVC) | H.264 and H.265 encoding | |
Region Of Interest (ROI) | 4 fixed regions for main stream | |
Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC | |
Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) | |
Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz | |
Environment Noise Filtering | Yes | |
Simultaneous Live View | Up to 6 channels | |
API | Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP | |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets | |
User/Host | Up to 32 users. 3 user levels: administrator, operator and user | |
Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2 | |
Network Storage | NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported. | |
Client | iVMS-4200,Hik-Connect | |
Web Browser | Plug-in required live view: IE 11, Plug-in free live view: Safari 12+, Local service: Chrome 57.0+, Firefox 52.0+, Not recommended: Safari 11+, Edge | |
Wide Dynamic Range (WDR) | 120 dB | |
Day/Night Switch | Day,Night,Auto,Schedule,Alarm Trigger | |
Image Enhancement | BLC, HLC, 3D DNR, Defog | |
Image Parameters Switch | Yes | |
Image Settings | Rotate mode,saturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser | |
Picture Overlay | LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format. | |
Privacy Mask | 8 programmable polygon privacy masks | |
Audio | 1 input (line in), 3.5 mm connector, three-contact, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), 3.5 mm connector, three-contact, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound | |
Alarm | 1 input(s), 1 output(s) (max. 36 VDC, 30 mA) | |
On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB | |
Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
Basic Event | Motion detection,video tampering alarm,network disconnected,IP address conflict,illegal login,HDD full,HDD error,abnormal reboot,alarm input and output,video quality diagnosis | |
Smart Event | scene change detection,audio exception detection,defocus detection | |
Linkage | Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture | |
Power | 12 VDC ± 20%, 0.58 A, max. 7.0 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: 802.3af, Type 1, Class 3, 36 V to 57 V, 0.25 A to 0.16 A, max. 9.0 W | |
Dimension | 164.3 mm × 84.6 mm × 67.4 mm (6.5" × 3.3" × 2.7") | |
Package Dimension | 227 mm × 172 mm × 125 mm (8.9" × 6.8" × 4.9") | |
Weight | Approx. 770 g (1.7 lb.) | |
With Package Weight | Approx. 1053 g (2.3 lb.) | |
Storage Conditions | -20 °C to 60 °C (-4 °F to 140 °F). Humidity 95% or less (non-condensing) | |
Startup And Operating | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) | |
Language | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian | |
General Function | Heartbeat,mirror,flash log,password reset via email,password protection,one-key reset,anti-banding | |
