5G High performance Bridge and Extender

Share on (10000014395205):


Price:$9.00 - $14.00

Quantity:


Product Overview

Description



Product Description


MKR07 is an 11N Wi-Fi 4 wireless router. It adopts MediaTek MT7628 chipset, comply with IEEE 802.11b/g/n standard, the Wi-Fi data rate is up to 300Mbps, providing excellent high-speed and superior experience when you surf on the internet, stream HD videos or play games. 2.4GHz WiFi has better wall pass through and wide coverage. Perfectly suitable to use outdoor as it is waterproof and lighting proof.








MKR07 Features


 ·  The 4G network can be converted into a wireless and wired network, and can also be connected to a broadband network to be converted into a wireless wired network . When both are connected at the same time, the wired network is given priority


·  Wireless rate 300Mbps


·  2 10/100Mbps adaptive network ports


·  Support WPA-PSK, WPA2-PSK, WPA-PSK/WPA2-PSK encryption protocol


·  Comply with IEEE 802.11b/g/n 2.4GHz standard protocol, IEEE802.3, IEEE802.3u standard protocol





Specifications











































































































































































Hardware Specifications












Hardware Configuration



CPU Processor



MTK7628 main frequency 580Mhz



DDR memory



64M



Flash memory



8M



Antenna



2.4G antenna







4G antenna



2 external 5DB omnidirectional antennas






4G Module _


(EC200-CN)



Support full Netcom (Mobile, China Unicom, China Telecom)


LTE FDD: B1/B3/B5/B8


LTE TDD: B34/B38/B39/B40/B41


WCDMA: B1/B5/B8


GSM: 900/1800MHz






Physical Interface



Network Interface



2 10 /100M adaptive LAN ports ( Auto MDI/MDIX )



power interface



DC 12V



POE power supply interface



2 POE 24V power supply



SIM card slot



1 supports 4G standard card 25*15mm



Indicator Light



Status Indicator



Power , LAN1 , LAN2 , SYS , 4G , 2.4G



Button



Reset Button



Through this button, the parameter configuration of the ROUTER can be restored to the factory value



Powered By



DC power supply



DC 12V/1A power supply



POE power supply



2 POE 24V power supply






Specification



Product Size







Product Weight







Color box size

























None


Wire


Ginseng


Number



Modulation



OFDM/BPSK/QPSK/DQPSK/DBPSK



RF Frequency Range



2412GHz ~ 2472GHz



Wireless Channel



2.4GHz Channel : 1,2,3,4,5,6,7,8,9,10,11,12,13









Transmission Rate



11b: 11M, 5.5M, 2M, 1Mbps


11g: 54M, 48M, 36M, 24M, 18M, 12M, 9M, 6Mbps


HT20: 6.5M, 13M, 19.5M, 26M, 39M, 52M, 58.5M, 65M, 13M, 26M, 39M, 52M, 78M, 104M, 117M 81M, 104M, 108M, 117M, 130M


HT40: 13.5M, 27M, 40.5M, 54M, 81M, 108M, 121.5M, 135M, 27M, 54M, 81M, 108M, 162M, 216M, 243M, 270M









Output Power


(2.4G)



802.11b



11Mbps



20.0 ± 2.0dBm



802.11g



6Mbps (-25@ EVM )



MCS 7



18.0 ± 2.0dBm



54Mbps (-25 @EVM )



MCS 7



17.0 ± 2.0dBm



802.11n _



HT20 (-30 @EVM )



MCS 7



15.0 ± 2.0dBm



HT40 ( -30 @EVM )



MCS 7



15.0 ± 2.0dBm









Sensitivity (2.4G)



802.11b



11Mbps



 -90dBm



802.11g _



6 Mbps



 -88dBm _



54 Mbps



 - 68 dBm



802.11n _



HT20



MCS 7



 - 66 dBm



HT40



MCS 7



 - 65 dBm









Environmental Standards



Working temperature: -25~+60°C



Working humidity: 10%~95% RH (non-condensing)



Storage temperature: -40~+80°C



Storage humidity: 10%~95% RH (non-condensing)
