Key sales CCD Line under vehicle inspection car scanning system for important places
- Category: >>>
- Supplier: Shenzhen Zhongangaoke Electronic Co. Ltd
Share on (10000014456183):
Product Overview
Description
Product Description
Key Sales CCD Line Mobile Under vehicle surveillance system UVSS for security
| Embedded Screening Part | |
| Camera | Sensor: line scans CCD, |
| Resolution | 5000*2048 pixels, Power Supply: 24VDC, 3A |
| Illumination | LED |
| Power Supply | 24VDC, 120W |
| Size | 1200mm x 350mm x 300mm |
| Operating Temperature Range | -20 degree to +60 degree |
| Input | 2 channels induction coil |
| Output | 1 Channel switch type 12VDC |
| Communication port | RS485, Ethernet (Optional) |
| Operating Temperature | -10℃ to 55℃ |
| System Host | |
| Brand | Grantech (SYM76941VGGA) |
| CPU | Intel(R)Celeron(R)CPU,E3400,2.6GHz 2.59 GHz |
| Memory | 2G( optional 4G) |
| Graphics | 512M |
| Hard Disk | SATA2 Hard Disk 500G |
| Dual LAN | At least one Intel Gigabit |
| USB2.0 | Up to 2 pieces |
| Monitor | 22inch LCD, resolution up to 1920*1080 |
Features
Automatic digital line scan camera, with high-resolution and clarity of the image.
The complete image of under vehicle scanning, without any omissions,
and the image is clear, complete, no distortion, can be clearly observed that
the object is not less than 2mm in diameter.
Preparation of inspection processes to meet a variety of on-site needs.
Multiple scene image monitoring, recording function.
Multi-language user interface design.
Strong scalability to easily achieve a variety of system linkage control.
(Optional)ALPR(Automatic Licence Plate Recognition)
(E.g.: anti-collision system, barrier, etc.).
(Optional) Multiple devices networked control functions.
Company Information
Packaging & Shipping
wooden packaging
