Multifunction Handheld 4 in 1 Laser Welder Relfar Double Wobble Fiber Laser Welding Machines
- Category: >>>
- Supplier: Shenzhen Dapeng Laser Equipment Co. Ltd.
Share on (10000019182019):
Product Overview
Description
Multifunction Handheld 4 in 1 Laser Welder Relfar Double Wobble Fiber Laser Welding Machines
| Model | DP-HL-1000 | DP-HL-1500 | DP-HL-2000 | DP-HL-3000 |
| Laser Power | 1000W | 1500W | 2000W | 3000W |
| Laser Source | Raycus/Max/IPG/BWT/Reci | Raycus/Max/IPG/BWT/Reci | Raycus/Max/IPG/BWT/Reci | Raycus/Max/IPG/BWT/Reci |
| Laser Head | Relfar Double Wobble | Relfar Double Wobble | Relfar Double Wobble | Relfar Double Wobble |
| Function | Welding / Cleaning / Cutting | Welding / Cleaning / Cutting | Welding / Cleaning / Cutting | Welding / Cleaning / Cutting |
| Fiber Wire Length | 5/10 Meters | 5/10 Meters | 5/10 Meters | 5/10 Meters |
| Laser Wavelength | 1070nm | 1070nm | 1070nm | 1070nm |
| Operate Mode | Continuation/Modulate | Continuation/Modulate | Continuation/Modulate | Continuation/Modulate |
| Water Chiller | BinYue | BinYue | BinYue | BinYue |
| Spot Adjusting Range | 0.1-3mm | 0.1-3mm | 0.1-3mm | 0.1-3mm |
| Repeating Precision | ±0.01mm | ±0.01mm | ±0.01mm | ±0.01mm |
| Cabinet Size | 744*941*1030mm | 744*941*1030mm | 750*1260*1110mm | 750*1260*1110mm |
| Machine Weight | About 200KG | About 200KG | About 220KG | About 220KG |
| Voltage | 110V/220V/380V | 110V/220V/380V | 110V/220V/380V | 110V/220V/380V |
