■Product introduction
Geocell is made of high-strength geosynthetics, which is popular with both domestic and abroad,which welding the strengthened HDPE sheets by the high-power ultrasonic and forming to be a structure of three-dimensional reticular formation. Easily folding and convenient for transportation.
When be in construction, the geocell can be pull into a network and launched into a three-dimensional honeycomb grid.
As it filled in soil, macadam, concrete or other granular materials, constituted to be a construction, which has strong sidewise restraint and high rate of stiffness.

■Product features
1. Geocell with retractile, transport contractible, when construction into a mesh, fill in the soil, gravel, loose materials such
as concrete, structure with strong lateral limitations and takong degree structure.
2.Change the geocell height, welding such as geometrical size can meet different engineering needs.
3. Higher lateral restrict and prevent slippery, prevent deformation, effectively enhance the bearing capacity of subgrade and scattered loads.
4. Raw material is qualitative light, wear resistance, stable chemical performance, light oxygen aging resistance, acid and alkali resistance, suitable for different soil and soil conditions, such as desert.

■Product application
1. Pavement subgrade stabilization
2. Area /Ground stabilization
3. Pavement base reinforcement
4. Working & load transfer platforms
5. Rail Track-bed stabilization
6. Reinforced granular foundation beds



HDPE Geocell Product Properties
Spec
Height
(mm)
Welding distance
(mm)
Sheet thickness(mm)
Seam peel
strength≥(N)
Expanded Cell
Size(mm)
Expanded
panel size(m)
smooth
textured
TGLG-75-330
75
330
1.1
1.5
1065
244×203
2.44×6.15
TGLG-100-330
100
1.1
1.5
1420
TGLG-150-330
150
1.1
1.5
2130
TGLG-200-330
200
1.1
1.5
2840
TGLG-75-356
75
356
1.1
1.5
1065
259×224
2.56×6.52
TGLG-100-356
100
1.1
1.5
1420
TGLG-150-356
150
1.1
1.5
2130
TGLG-200-356
200
1.1
1.5
2840
TGLG-75-400
75
400
1.1
1.5
1065
295×250
4×5
TGLG-100-400
100
1.1
1.5
1420
TGLG-150-400
150
1.1
1.5
2130
TGLG-200-400
200
1.1
1.5
2840
TGLG-75-445
75
445
1.1
1.5
1065
320×287
2.56×8.35
TGLG-100-445
100
1.1
1.5
1420
TGLG-150-445
150
1.1
1.5
2130
TGLG-200-445
200
1.1
1.5
2840
TGLG-75-660
75
660
1.1
1.5
1065
488×406
2.44×12.29
TGLG-100-660
100
1.1
1.5
1420
TGLG-150-660
150
1.1
1.5
2130
TGLG-200-660
200
1.1
1.5
2840
TGLG-75-712
75
712
1.1
1.5
1065
508×475
2.56×13.72
TGLG-100-712
100
1.1
1.5
1420
TGLG-150-712
150
1.1
1.5
2130
TGLG-200-712
200
1.1
1.5
2840
Notes:(1) Other welding distance can be made:356mm,450mm,500mm,660mm etc.
(2)The special spec or size can be manufactured according to the demands of the contract.
